John Deere 5075GV
John Deere 5075GV — 5G Series · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
5379 to 6051 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectrohydraulicReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post foldable mid-mount ROPS. Cab optional with air-conditioning.Reference
Variants
5075GNnarrowReference
5075GVvineyardReference
Engine
FPT 3.4L 4-cyl dieselReference
Fuel tank85.9 LReference
Engine (gross)55.9 kWReference
FPTReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke99 x 110 mmReference
EmissionsTier IVReference
Rated Power (gross)55.9 kWReference
Cooling systemviscous fanReference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
12-speedReference
TransmissionPowrReverserReference
Gears24 forward and 12 reverseReference
Clutchwet discReference
Four gears (1-4) in three ranges (A-C) with push-button high-low shift and power shuttle.Reference
TransmissionSyncReverserReference
Gears12 forward and reverseReference
Clutchdry discReference
Four gears (1-4) in three ranges (A-C) with synchronized shuttle.Reference
PTO & Hydraulics
Typeopen centerReference
Rear valves0 to 4Reference
Mid valves0 to 4Reference
Pump flow66.6 lpmReference
Pump flow29.9 lpmReference
Total flow96.5 lpmReference
Total flow126.4 lpmReference
Steering flow29.9 lpmReference
Rear TypeIIReference
Controlcenter link draft sensingReference
Rear lift (at ends)2590 kgReference
Rear lift (at ends)3099 kgReference
Rear Armsfixed ball endsReference
Rear Armsadjustable ball endsReference
Rear PTOindependentReference
Clutchmechanical dry discReference
Clutchhydraulic wet discReference
Rear PTO Type540/540EReference
Dimensions
Weight5379 to 6051 poundsReference
Width108 cmReference
Flange rear axle891 mmReference
2WD ROPS2439 kgReference
4WD ROPS2529 kgReference
2WD Cab2654 kgReference
4WD Cab2744 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
