Tractor · 2005Unverified

John Deere 50C

Name: John Deere 50C
Brand: John Deere

John Deere 50C — Milenio C Series · 49 hp. Reference specifications; pending source verification.

The John Deere 50C is a compact tractor rated at 49 hp, making it a more compact option in its class. Manufactured from 2005 to 2015, it is equipped with a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 16-speed gearbox. The tractor weighs 1900 kg and is suited for jobs covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

49 hp

Max power

49 hp

Weight

1900 kg

Catalogue coverage

Variants represented

Richest spec table

89 rows

Recorded power

49 hp

Recorded weight

1900 kg

Transmissions

16-speed

Production years

2005-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post mid-mount folding ROPS.Reference

Engine

VM Motori 2.1L 3-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)36.5 kWReference

VM Motori D703Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.1 LReference

Bore/Stroke94 x 100 mmReference

Rated Power (gross)36.5 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Rated RPM2600Reference

Torque145.1 NmReference

Torque RPM1200Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.0 LReference

Coolant capacity9.0 LReference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,600 RPMReference

Engine torque at rated speed48.5 kgReference

Bore and stroke3.70x3.94 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speedReference

8-speedReference

Gears16 forward and 8 reverseReference

Clutchmechanical dry discReference

Oil capacity35.0 LReference

Gears8 forward and reverseReference

forward and reverse options16F and 8R | 8F and 8RReference

Wheel Drive4WDReference

PTO & Hydraulics

Pressure180.0 barReference

Pump flow39.0 lpmReference

Rear TypeII/IReference

Rear lift (at ends)2300 kgReference

Rear lift (at 24"/610mm)1450 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Engine RPM540@2430Reference

Engine RPM540E@1874Reference

Dimensions

Wheelbase168 cmReference

Weight1900 kgReference

Front tire240/70R16Reference

Rear tire320/70R24Reference

Standard tires (ag)Front: 240/70R16. Rear: 320/70R24Reference

Length325 cmReference

Width129 cmReference

Height (ROPS)249 cmReference

Height (cab)216 cmReference

Front tread99 to 147 cmReference

Rear tread103 to 144 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery volts12Reference

General

Make & ModelGoldiniReference

Rollover protective structureTwo-post mid-mount folding ROPSReference

Country of manufacturerItalyReference

Capacities

Capacity127.1 ciReference

Crankcase oil volume5.3 qtsReference

Power

Max Power49 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,430 RPMReference

Steering & brakes

BrakesMechanical Wet DiscReference

Steering typePowerReference

Hydraulics

Maximum operating pressure2,611 psiReference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity2,300.2 kgReference

Dimensions & weight

Height Over Cab216.9 cmReference

Height Over ROPS249.9 cmReference

Overall Length325.1 cmReference

Overall Width129 cmReference

Overall weight1,900.1 kgReference

Wheels & tyres

Rear Wheel Type320/70R24Reference

Rear wheel tread range40.9 to 56.7 inchesReference

Front Wheel Type240/70R16Reference

Front Wheel tread range39.3 to 58 inchesReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
