Tractor · 2002Unverified
John Deere 50F
John Deere 50F — Milenio F Series · 49 hp. Reference specifications; pending source verification.
The John Deere 50F is a tractor with a power output of approximately 49 hp, positioned at the lower end of its class. Production of this model spanned the period from 2002 to 2010. It is equipped with a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. The operating weight of the tractor is listed at 2029 kg, with a suitable operating area of up to 200 ac.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Weight
2029 kg
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
49 hp
Recorded weight
2029 kg
Transmissions
16-speed
Production years
2002-2010
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
VM Motori 2.1L 3-cyl dieselReference
Engine (gross)36.5 kWReference
VM Motori D703Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke94 x 100 mmReference
Rated Power (gross)36.5 kWReference
Rated RPM2600Reference
Torque145.1 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
8-speedReference
Gears16 forward and 8 reverseReference
Clutch254mm mechanical dry discReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow39.0 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2300 kgReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase173 cmReference
Weight2029 kgReference
Front tire8.25-16Reference
Rear tire340/85-24Reference
Standard tires (ag)Front: 8.25-16. Rear: 340/85-24Reference
Length350 cmReference
Height219 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
