5M Series · 2024 John Deere 5100M John Deere 5100M: 100 hp tractor — 4.5 L engine, 3670 kg rear lift. Verified specs with sources, UK & US units.
The John Deere 5100M is a tractor with a rated output of 100 hp — putting it around the middle of its class for power. It was introduced in 2024. Under the hood is a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive. Listed weight is 3700 kg, and it is aimed at jobs of around 200–800 ac. The available specification table below shows both UK and US units.
Richest spec table
44 rows
1 linked source document displayed
Specifications Description Maintenance Troubleshooting Ownership Reviews Q&A Docs & sources
Hover a source tag to verify UK metric US imperial
Rated power 75 kW (100 hp) OEM
Emissions stage Stage V EPA cert
Engine 4.5 L Dealer
Fuel Type Diesel Reference
No of Cylinders 4 cylinder Reference
Rated engine speed 2,100 RPM Reference
Bore and stroke 4.19x5.00 inches Reference
Cooling system liquid-cooled Reference
Rear lift capacity 3670 kg Reference
Hydraulic flow 74 L/min Dealer
Wheelbase 2250 mm Dealer
Weight 3700 kg Dealer
Make & Model John Deere Reference
Differential lock electro-hydraulic Reference
SCV control Joystick Reference
Rollover protective structure Two-post foldable ROPS Reference
Country of manufacturer USA Reference
Capacity 276 ci Reference
Fuel tank 140.1 L Reference
PTO Power 85 hp Reference
Rear PTO Power Available Reference
Rear PTO RPM 1,000 RPM Reference
Transmission Type Power Shuttle Reference
Wheel Drive 4WD Reference
Clutch Wet Disc Reference
Rear Axle Drive Type inboard planetary Reference
Brakes Hydraulic wet disc brakes Reference
Steering type Power steering Reference
Pump Rated Output (total) 24.7 gpm Reference
Hydraulics Type Open Center Reference
Maximum operating pressure 2,828 psi Reference
Remote Valves Rear valves:2 or 3 | Mid valves:2 or 3 Reference
Steering & Implements flow 6.3 gpm (18.4 gpm) Reference
Rear Hitch category (SAE designation) Category II/I Reference
Rear Hitch Sensing Type lower-link draft sensing Reference
Height Over ROPS 250.2 cm Reference
Height Over Cab 257.8 cm Reference
Overall Length 414 cm Reference
Overall weight 3,628.7 kg Reference
Rear Wheel Type 2WD Rear: 18.4R30 | 4WD Rear: 460/85R30 ag Reference
Front Wheel Type 2WD Front: 12.4R24. | 4WDFront: 320/85R24. Reference
Cab Availability Available Reference
Seat Suspension TRUE Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
