Tractor · 2018Unverified
John Deere 5125ML
John Deere 5125ML — Orchard/Vineyard tractor · 123 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
123 hp
Max power
88.5 kW
Weight
3964 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Manual steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS.Reference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank143.8 LReference
Exhaust fluid (DEF)12.1 LReference
Engine (gross)91.9 kWReference
Drawbar (tested)72.3 kWReference
John DeereReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Rated Power (gross)91.9 kWReference
StarterelectricReference
Starter volts12Reference
Max power88.5 kWReference
Power at rated engine speed84.6 kWReference
Max power72.3 kWReference
Transmission
16-speed four-speed power shiftReference
32-speed four-speed power shiftReference
TransmissionPowrQuadReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Clutchwet discReference
TransmissionPower 8Reference
Gears32 forward and 16 reverseReference
PTO & Hydraulics
PTO (claimed)85.8 kWReference
PTO (tested)88.5 kWReference
Typeclosed centerReference
Rear valves3Reference
Mid valves0 to 2Reference
Pump flow117.3 lpmReference
SCV flow99.9 lpmReference
Rear TypeIIReference
Rear lift3163 kgReference
Rear lift3568 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000Reference
Engine RPM540@2100Reference
Engine RPM540E@1645Reference
Engine RPM1000@2103Reference
Power at rated PTO speed86.1 kWReference
Dimensions
Wheelbase234 cmReference
Weight3964 kgReference
Width131 cmReference
Height (ROPS)226 cmReference
Height (Folded ROPS)172 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Test results
Diesel 16-speed 4WDApril 30 - May 6, 2019Link: OCED Tractor Test 2211 fileReference
PTO performanceReference
Fuel use24.6 l/hourReference
Fuel use25.0 l/hourReference
Drawbar performanceReference
Fuel use25.4 l/hourReference
Max pull3740 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
