Tractor · 2003Unverified
John Deere 5215 F
John Deere 5215 F — Orchard/Vineyard tractor · 56 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerAgritaliaReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanicalReference
Differential lockelectro-hydraulicReference
Power steeringReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Two-post folding mid-mount ROPS. Cab optional with available air-conditioning.Reference
Variants
5215ForchardReference
5215VvineyardReference
Engine
John Deere 2.9L 3-cyl dieselReference
Fuel tank74.9 LReference
Engine (gross)41.8 kWReference
Engine (net)41.0 kWReference
John DeereReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
EmissionsTier IIReference
Rated Power (net)41.0 kWReference
Rated Power (gross)41.8 kWReference
Compression17.2:1Reference
Rated RPM2300Reference
Idle RPM825-2510Reference
Operating RPM1200-2300Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed partially synchronizedReference
24-speed partially synchronizedReference
24-speed power shuttleReference
Typepartially synchronizedReference
Gears12 forward and reverseReference
Four synchronized gears (1-4) in three ranges (A-C) with mechanical shuttle. Tractor must be stopped, and clutch used, to shift range.Reference
TransmissionHi-LoReference
Gears24 forward and reverseReference
The Hi-Lo transmission adds an additional two-speed shift to the base transmission. The Hi-Lo can be either electronic or mechanical. Mechanical is operator with a sliding lever and requires the clutch. Electro-hydraulic is a push-button shift.Reference
TransmissionPower ReverserReference
Typepower shuttleReference
Gears24 forward and 12 reverseReference
Four synchronized gears (1-4) in three ranges (A-C) with power shuttle and power shift Hi-Low. Push-button clutch for gear shifting.Reference
PTO & Hydraulics
Typeopen centerReference
Pressure190.0 barReference
Pump flow41.3 lpmReference
Steering flow24.6 lpmReference
Rear TypeII/I/INReference
Rear lift2447 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Engine RPM540@1938Reference
Engine RPM540E@1648Reference
Engine RPM1000@1962Reference
Dimensions
2WD Wheelbase195 cmReference
4WD Wheelbase196 cmReference
Front tire250/80R18Reference
F 4WD Rear tire380/70R28Reference
F 4WD Standard tires (ag)Front: 250/80R18. Rear: 380/70R28Reference
Length342 cmReference
F Width133 cmReference
V 2WD Width104 cmReference
V 4WD Width115 cmReference
F Rear tread99 to 159 cmReference
V Rear tread93 to 121 cmReference
Steering wheel145 cmReference
5215 F Serial Numbers
Location:Serial number plate on the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps40Reference
Cab Charging amps60Reference
Battery volts12Reference
Battery AH100Reference
John Deere 5215 F Height
ROPS223 cmReference
Cab223 cmReference
Speeds
With 380/70R28 rear tires.Reference
With 380/70R28 rear tires. Reverse speeds are 10% slower than forward.Reference
With 380/70R28 rear tires. Reverse speeds are 10% slower than the forward high range.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
