Tractor · 2003Unverified

John Deere 5315 F

Name: John Deere 5315 F
Brand: John Deere

John Deere 5315 F — Orchard/Vineyard tractor · 67 hp. Reference specifications; pending source verification.

The John Deere 5315 F is a tractor with a rated power output of 67 hp, a mid-range figure for its class. It was manufactured between 2003 and 2008. The tractor features a 3-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

67 hp

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

67 hp

Transmissions

12-speed partially synchronized

Production years

2003-2008

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerAgritaliaReference

Orchard/Vineyard tractorReference

Built in ItalyReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanicalReference

Differential lockelectro-hydraulicReference

Power steeringReference

Wet disc brakesReference

Trailer brakeshydraulicReference

Two-post folding mid-mount ROPS. Cab optional with available air-conditioning.Reference

Variants

5315ForchardReference

5315VvineyardReference

Engine

John Deere 2.9L 3-cyl dieselReference

Fuel tank74.9 LReference

Engine (gross)49.6 kWReference

Engine (net)48.5 kWReference

John DeereReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke106 x 110 mmReference

EmissionsTier IIReference

Rated Power (net)48.5 kWReference

Rated Power (gross)49.6 kWReference

Compression17.2:1Reference

Rated RPM2300Reference

Idle RPM825-2510Reference

Operating RPM1200-2300Reference

Firing order1-2-3Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed partially synchronizedReference

24-speed partially synchronizedReference

24-speed power shuttleReference

Typepartially synchronizedReference

Gears12 forward and reverseReference

Four synchronized gears (1-4) in three ranges (A-C) with mechanical shuttle. Tractor must be stopped, and clutch used, to shift range.Reference

TransmissionHi-LoReference

Gears24 forward and reverseReference

The Hi-Lo transmission adds an additional two-speed shift to the base transmission. The Hi-Lo can be either electronic or mechanical. Mechanical is operator with a sliding lever and requires the clutch. Electro-hydraulic is a push-button shift.Reference

TransmissionPower ReverserReference

Typepower shuttleReference

Gears24 forward and 12 reverseReference

Four synchronized gears (1-4) in three ranges (A-C) with power shuttle and power shift Hi-Low. Push-button clutch for gear shifting.Reference

PTO & Hydraulics

Typeopen centerReference

Pressure190.0 barReference

Pump flow41.3 lpmReference

Steering flow24.6 lpmReference

Rear TypeII/I/INReference

Rear lift2447 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Engine RPM540@1938Reference

Engine RPM540E@1648Reference

Engine RPM1000@1962Reference

Dimensions

2WD Wheelbase195 cmReference

4WD Wheelbase196 cmReference

Front tire250/80R18Reference

F 4WD Rear tire380/70R28Reference

F 4WD Standard tires (ag)Front: 250/80R18. Rear: 380/70R28Reference

Length342 cmReference

F Width133 cmReference

V 2WD Width104 cmReference

V 4WD Width115 cmReference

F Rear tread99 to 159 cmReference

V Rear tread93 to 121 cmReference

Steering wheel145 cmReference

5315 F Serial Numbers

Location:Serial number plate on the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps40Reference

Cab Charging amps60Reference

Battery volts12Reference

Battery AH100Reference

John Deere 5315 F Height

ROPS223 cmReference

Cab223 cmReference

Speeds

With 380/70R28 rear tires.Reference

With 380/70R28 rear tires. Reverse speeds are 10% slower than forward.Reference

With 380/70R28 rear tires. Reverse speeds are 10% slower than the forward high range.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
