John Deere 540A
John Deere 540A — ???? - 1975 Skidder · 104 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
104 hp
Weight
5828 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
SkidderReference
FactoriesDubuque, Iowa, USAReference
FactoriesWelland, Ontario, CanadaReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockhydraulic frontReference
Articulated power steeringReference
Hydraulic disc brakesReference
Four-post ROPS.Reference
Engine
John Deere 5.4L 6-cyl dieselReference
Engine (gross)77.6 kWReference
Engine (net)70.1 kWReference
John DeereReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.4 LReference
Bore/Stroke102 x 110 mmReference
Power (net)70.1 kWReference
Power (gross)77.6 kWReference
Air cleanerdryReference
Compression16.7:1Reference
Rated RPM2500Reference
Torque325.4 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity14.2 LReference
Coolant capacity22.7 LReference
Transmission
8-speed full power shiftReference
Typefull power shiftReference
Gears8 forward and 4 reverseReference
Clutchhydraulic wet discsReference
Oil capacity30.3 LReference
Capacities
Fuel159.0 LReference
Front diff.30.3 LReference
Rear axle17.0 LReference
PTO & Hydraulics
Typeclosed centerReference
Pressure137.9 barReference
Pump flow106.0 lpmReference
Dimensions
Wheelbase262 cmReference
Weight5828 kgReference
Front tire18.4-26Reference
Rear tire18.4-26Reference
Industrial front18.4-26Reference
Industrial rear18.4-26Reference
Industrial front18.4-34Reference
Industrial front23.1-26Reference
Industrial front28.1-26Reference
Industrial rear18.4-34Reference
Industrial rear23.1-26Reference
Industrial rear28.1-26Reference
Height (ROPS)289 cmReference
Operating weight5828 kgReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
