Industrial Tractor · 1974Unverified
John Deere 544B
John Deere 544B — Wheel Loader · 115 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
9756 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Wheel LoaderReference
Four-wheel driveReference
Final drivesinboard planetaryReference
Articulated power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS with canopy. Cab optional.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Fuel tank151.4 LReference
Engine (gross)85.8 kWReference
Engine (net)78.3 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
Power (net)78.3 kWReference
Power (gross)85.8 kWReference
Air cleanerdryReference
Rated RPM2200Reference
Torque440.7 NmReference
Torque RPM1300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity30.3 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and 2 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure155.1 barReference
Pump flow168.4 lpmReference
Steering flow100.3 lpmReference
Steering press.162.0 barReference
Dimensions
Wheelbase240 cmReference
Weight9756 kgReference
Front tire17.5-25Reference
Rear tire17.5-25Reference
Industrial front17.5-25Reference
Industrial rear17.5-25Reference
Industrial front14.00-24Reference
Industrial rear14.00-24Reference
Length579 cmReference
Operating weight9756 kgReference
Ground clearance36 cmReference
Front tread177 cmReference
Rear tread177 cmReference
John Deere 544B attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery CCA625Reference
Battery volts12Reference
John Deere 544B Height
ROPS297 cmReference
Cab309 cmReference
Exhaust307 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
