Tractor · 2005Unverified
John Deere 5525 Hi-Crop
John Deere 5525 Hi-Crop — High-Clearance tractor · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Max power
58.1 kW
Weight
3240 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
High-Clearance tractorReference
Built in Augusta, Georgia, USAReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Two-post ROPS on straddle-deck. Flat-deck platform optional.Reference
Variants
5525utilityReference
5525Nnarrow-profileReference
5525 Hi-Crophigh-clearanceReference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank96.5 LReference
Engine (gross)67.9 kWReference
John DeereReference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
EmissionsTier IIReference
Power (gross)67.9 kWReference
Air cleanerpaper and felt elementsReference
Compression17.6:1Reference
Rated RPM2400Reference
Idle RPM825-2625Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Coolant capacity11.4 LReference
Oil capacity8.5 LReference
Max power58.1 kWReference
Power at rated engine speed56.7 kWReference
Transmission
12-speed partially synchronizedReference
16-speed power shuttleReference
TransmissionJohn Deere SyncShuttleReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
TransmissionJohn Deere PowrReverserReference
Typepower shuttleReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
PTO (tested)58.1 kWReference
Typeopen centerReference
Rear valves0 to 3Reference
Mid valves0 to 3Reference
Pump flow69.6 lpmReference
Steering flow25.0 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1530 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/540E optionalReference
Dimensions
Wheelbase217 cmReference
Weight3240 kgReference
Front tire13.6-38Reference
Rear tire13.6-38Reference
Ag front13.6-38Reference
Ag front230/95R40Reference
Ag rear13.6-38Reference
Ag rear230/95R40Reference
Height280 cmReference
Shipping weight3240 kgReference
Ground clearance64 cmReference
5525 Hi-Crop Serial Numbers
Location:Left side of tractor frame above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps70Reference
Battery CCA950Reference
Battery volts12Reference
Battery GroupBCI 31Reference
Test results
Diesel 12-speed 4WDNovember 15 - 23, 2005Link: Nebraska Tractor Test 1869 fileReference
PTO performanceReference
Fuel use19.7 l/hourReference
Fuel use20.4 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
