Tractor · 2007Unverified
John Deere 5603
John Deere 5603 — Utility tractor · 99 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
99 hp
Max power
62.5 kW
Weight
3240 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Augusta, Georgia, USAReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard.Reference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine (gross)73.8 kWReference
John Deere PowerTech 4045Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
EmissionsTier IIReference
Power (gross)73.8 kWReference
Air cleanerpaper and felt elementsReference
Compression17.0:1Reference
Rated RPM2400Reference
Idle RPM825-2625Reference
Starter volts12Reference
Coolant capacity11.4 LReference
Coolant change2100 hReference
Oil capacity8.5 LReference
Oil change300 hReference
Max power62.5 kWReference
Power at rated engine speed61.8 kWReference
Transmission
12-speed power shuttleReference
TransmissionPowrReverserReference
Typepower shuttleReference
Gears12 forward and reverseReference
Clutchwet discReference
Oil capacity43.5 LReference
Four gears (1-4) in three ranges (A-C) with left-hand reverser lever. Forward to rear shuttle shifting may be done while moving without the clutch. Gear shifts (1-4) are synchronized with the clutch. The tractor must be stopped to shift ranges.Reference
PTO & Hydraulics
PTO (claimed)61.1 kWReference
PTO (tested)62.5 kWReference
Hydraulic system43.5 LReference
Typeopen centerReference
Capacity43.5 LReference
Valves1 to 3Reference
Pump flow60.2 lpmReference
Total flow85.2 lpmReference
Rear Type1/2Reference
Rear lift (at 24"/610mm)1530 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Engine RPM540@2400Reference
Engine RPM540E@1700Reference
Capacities
Fuel126.8 LReference
Front hubs0.7 LReference
Front diff.4.5 LReference
Dimensions
Wheelbase217 cmReference
Weight3240 kgReference
Front tire12.4-24Reference
Rear tire18.4-30Reference
Ag front12.4-24Reference
Ag rear18.4-30Reference
Ground clearance40 cmReference
Operating3240 kgReference
Max Drawbar759 kgReference
Max Drawbar1120 kgReference
5603 Serial Numbers
Location:Serial plate on the front-left tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Charging amps120Reference
Battery CCA750Reference
Battery volts12Reference
Battery Group31Reference
Test results
Diesel 12-speed 4WDSeptember 6 - 11, 2007Link: Nebraska Tractor Test 1905 fileReference
PTO performanceReference
Fuel use21.6 l/hourReference
Fuel use20.4 l/hourReference
Speeds
With 18.4R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
