Lawn Tractor · 1966Unverified
John Deere 60
John Deere 60 — Lawn tractor · 6 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
6 hp
Weight
182 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Lawn tractorReference
Built in Horicon, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
6HP Tecumseh 221cc 1-cyl gasolineReference
Fuel tank4.7 LReference
Tecumseh VH60Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement13.5 ciReference
Bore/Stroke67 x 64 mmReference
Power4.5 kWReference
Air cleanerdryReference
Rated RPM3600Reference
Idle RPM1800-3600Reference
Starter volts12Reference
Sparkplug gap0.762 mmReference
Point gap0.508 mmReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Oil capacity0.7 LReference
Oil change25 hReference
Transmission
6-speed gearReference
TransmissionPeerless 1200Reference
Typebelt-driven gearReference
Gears6 forward and 2 reverseReference
Oil capacity1.4 LReference
Oil typeAM30200MReference
Three gears plus reverse. The drive belt has two positions for high and low ranges. To change the range, tilt the rear fender backwards and change the drive belt position.Reference
1Clutch/BrakeReference
2ThrottleReference
3Gear shiftReference
4Parking brakeReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase107 cmReference
Weight182 kgReference
Front tire5.00x13Reference
Rear tire8.50x18Reference
Lawn/turf front5.00x13Reference
Lawn/turf rear8.50x18Reference
Length149 cmReference
Width77 cmReference
Height93 cmReference
Front tread59 cmReference
Rear tread57 cmReference
John Deere 60 attachments
34" mid-mount mower deckReference
snowblowerReference
bladeReference
60 Serial Number Location
Serial number plate below steering wheel.Reference
60 Serial Numbers
196600001Reference
196708001Reference
196815001Reference
196920001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH24Reference
Attachment overview
34" mid-mount mower deckReference
SnowblowerReference
BladeReference
34" Mower deck
Typemid-mount John DeereReference
Typemanual liftReference
Cutting width86 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
