Tractor · 1999Unverified
John Deere 6110
John Deere 6110 — Utility tractor · 84 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
84 hp
Max power
53.0 kW
Weight
7420 to 9645 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulicReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Two-post ROPS. ComfortGard cab optional with air-conditioning.Reference
Variants
6110utlity tractorReference
6110Llow-profileReference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank116.2 LReference
Fuel tank165.0 LReference
Engine (gross)62.6 kWReference
Drawbar (tested)46.2 kWReference
John Deere 4045TL053Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power (gross)62.6 kWReference
Compression16.9:1Reference
Rated RPM2300Reference
Operating RPM1500-2300Reference
Torque345.8 NmReference
Torque RPM1100Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Starter power3.1 kWReference
Oil capacity12.0 LReference
ROPS Coolant capacity11.0 LReference
Cab Coolant capacity13.5 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Max power53.0 kWReference
Power at rated engine speed50.5 kWReference
Max power46.2 kWReference
Transmission
12-speed fully synchronizedReference
16-speed four-speed power shiftReference
TransmissionSyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Clutchwet discReference
Three gears (1-3), plus reverse (R) in four ranges (A-D).Reference
TransmissionSyncroPlus Power ReverserReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Four synchronized gears (1-4) in four ranges (A-D) with left-hand power reverser.Reference
TransmissionPowrQuadReference
Clutchhydraulic wet discReference
Four power shift gears (1-4) in four synchronized ranges (A-D) with reverser.Reference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
PTO (tested)53.0 kWReference
Typeclosed center pressure-flow compensatingReference
Pressure200.0 barReference
Valves1 to 4Reference
Pump flow96.1 lpmReference
Pump flow71.5 lpmReference
Rear TypeIIReference
Controlelectronic lower-link draft sensingReference
Rear lift2152 kgReference
Front HitchoptionalReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2143Reference
Engine RPM540E@1684Reference
Engine RPM1000@2208Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@2185Reference
Power at rated PTO speed51.8 kWReference
Dimensions
Wheelbase240 cmReference
Weight7420 to 9645 poundsReference
Front tire7.50-18Reference
2WD Rear tire16.9-30Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 16.9-30Reference
4WD Standard tires (ag)Front: 12.4-24. Rear: 16.9-30Reference
Length413 cmReference
Width203 cmReference
2WD Clearance (front axle)58 cmReference
4WD Clearance (front axle)46 cmReference
Flange rear axleReference
Rack-and-pinion rear axle78 by 2268 mmReference
Rack-and-pinion rear axle78 by 2555 mmReference
2WD ROPS Shipping3365 kgReference
2WD Cab Shipping3595 kgReference
4WD ROPS Shipping3590 kgReference
4WD Cab Shipping3820 kgReference
4WD Cab Operating4374 kgReference
Steering wheel176 cmReference
John Deere 6110 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps90Reference
Cab Charging amps115Reference
Battery CCA830Reference
Battery CCA1230Reference
Battery volts12Reference
Battery AH110Reference
Battery AH154Reference
Attachment overview
John Deere 620 loaderReference
John Deere 640 loaderReference
John Deere 640SL loaderReference
John Deere 6110 Height
ROPS273 cmReference
Cab258 cmReference
Exhaust256 cmReference
Test results
Diesel PowerQuad 4WDOctober 1, 1998 - February 1, 1999Link: OCED Tractor Test 1833 fileReference
PTO performanceReference
Fuel use15.1 l/hourReference
Fuel use17.0 l/hourReference
Fuel use16.3 l/hourReference
Drawbar performanceReference
Gear 2C used for power test.Reference
Max pull2147 kgReference
Gear 1C used for pull test.Reference
Speeds
With 18.4-30 rear tires.Reference
With 18.4-30 rear tires. Reverse speeds are 20% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
