Tractor · 1999Unverified
John Deere 6110L
John Deere 6110L — Orchard/Vineyard tractor · 84 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
84 hp
Weight
7420 to 7916 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic wet discReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS.Reference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank116.2 LReference
Engine (gross)62.6 kWReference
John Deere 4045Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power (gross)62.6 kWReference
Rated RPM2300Reference
Torque345.8 NmReference
Torque RPM1100Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Starter power3.0 kWReference
Coolant capacity11.0 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Oil capacity12.1 LReference
Transmission
12-speed fully synchronizedReference
16-speed power shuttleReference
16-speed partial power shiftReference
38-speed four-speed power shiftReference
TransmissionJohn Deere SyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Oil capacity51.9 LReference
Oil type[30oC]Reference
-10oF [-23oC]↑: JD HY-GARDReference
86oF [30oC]↓: Low-Visocosity HY-GARDReference
Three gears, plus reverse, in four ranges.Reference
TransmissionJohn Deere SynchroPlus Power ReverserReference
Typepower shuttleReference
Gears16 forward and reverseReference
Four synchronized in four ranges, with power reverser.Reference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Oil capacity48.8 LReference
Oil type[30oC]Reference
86oF [30oC]↓: Low-Viscosity HY-GARDReference
Four power shift gears in four synchronized ranges, with reverser.Reference
TransmissionPowrQuad CreeperReference
Typefour-speed power shiftReference
Gears38 forward and reverseReference
Creeper option adds an additional low-speed for ranges A, B, and C.Reference
PTO & Hydraulics
PTO (claimed)48.5 kWReference
Typeclosed center load sensingReference
Pressure200.0 barReference
Valves1 to 4Reference
Pump flow96.1 lpmReference
Pump flow71.5 lpmReference
Rear TypeIIReference
Controlelectronic lower-link draft sensingReference
Rear lift2152 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase240 cmReference
Weight7420 to 7916 poundsReference
Front tire27/9.5-15Reference
2WD Rear tire16.9-24Reference
2WD Standard tires (ag)Front: 27/9.5-15. Rear: 16.9-24Reference
4WD Standard tires (ag)Front: 10.5/80-18. Rear: 16.9-24Reference
Length413 cmReference
Width165 cmReference
Orchard Width142 cmReference
2WD Shipping3365 kgReference
4WD Shipping3590 kgReference
Steering wheel164 cmReference
6110L Serial Numbers
Location:Serial number plate on the right side of the tractor frame.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Battery CCA850Reference
Battery CCA1230Reference
Battery volts12Reference
Battery AH110Reference
Battery AH154Reference
Capacities
Max capacity6999 kgReference
John Deere 6110L Height
2WD Hood158 cmReference
4WD Hood154 cmReference
ROPS237 cmReference
Speeds
With 18.4-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
