Tractor · 2008Unverified

John Deere 6115D

Name: John Deere 6115D
Brand: John Deere

John Deere 6115D — Model year 2008-20122013-2016 · 118 hp. Reference specifications; pending source verification.

The John Deere 6115D is a 118 hp tractor, positioned towards the middle of its class in terms of power output. It was produced from 2008 to 2016 and features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine. The tractor is equipped with four-wheel drive and a hydrostatic transmission, and its listed weight ranges from 7495 to 9390 pounds. It is designed for use on areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

118 hp

Max power

74.1 kW

Weight

7495 to 9390 pounds

Catalogue coverage

Variants represented

Richest spec table

159 rows

Recorded power

118 hp

Transmissions

9-speed partially synchronized with power shuttle

Production years

2008-2016

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Saltillo, MexicoReference

Original price$48,483 (2011)Reference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Independent mechanical wet disc brakesReference

Folding 2-post ROPS or cab with heat and A/CReference

Engine

John Deere 4.5L 4-cyl dieselReference

Engine (gross)88.3 kWReference

Drawbar (tested)60.3 kWReference

John Deere 4045H PowerTech EReference

intercooled turbocharged dieselReference

4-cylinder 8-valveReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke107 x 127 mmReference

EmissionsTier 3Reference

Rated Power (gross)88.3 kWReference

Fuel systemDenso electronic high-pressure common railReference

Air cleanertwo paper elementsReference

Compression19:1Reference

Rated RPM2100Reference

Idle RPM900-2200Reference

Torque481.4 NmReference

Torque RPM1500Reference

Firing order1-3-4-2Reference

Starter volts12Reference

Coolant capacity16.5 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Oil capacity15.0 LReference

Oil change250 hReference

Oil change500 h (JD TorqGARD oil)Reference

Max power74.1 kWReference

Power at rated engine speed73.9 kWReference

Max power60.3 kWReference

Fuel TypeDieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Emissions complianceInterim Tier IV | \\tcooled exhaust gas recirculationReference

Engine torque at rated speed161 kgReference

Bore and stroke4.17x5.00 inchesReference

Compression ratio19:1Reference

Cooling systemliquid-cooledReference

Interval for engine oil change500 hrReference

Transmission

9-speed partially synchronized with power shuttleReference

9-speed partially synchronziedReference

TransmissionJohn Deere PowrReverserReference

Typepartially synchronized with power shuttleReference

Gears9 forward and reverseReference

Clutchhydraulic wet discReference

Oil capacity57.9 LReference

Three gears (1-3) in each of three ranges (A-C) plus left-hand reverser. Forward/reverse powershift. Synchronized shift between gears with clutch. Shifts between ranges are unsynchronized: the tractor must be stopped and clutch used to shift range.Reference

TransmissionJohn Deere Top Shaft Syncronized (TSS)Reference

Typepartially synchronziedReference

Gears9 forward and 3 reverseReference

Clutchdry discReference

Three gears (1-3) plus reverse (R) in each of three ranges (A-C). Shifts between gears, including to reverse, are synchronized using the clutch. Shifts between ranges are not synchronized, the operator must stop the tractor and use the clutch.Reference

Transmission TypePower ShuttleReference

Wheel Drive4WDReference

Rear Axle Drive Typeinboard planetaryReference

PTO & Hydraulics

PTO (claimed)70.8 kWReference

PTO (tested)74.1 kWReference

Hydraulic system57.9 LReference

Typeopen centerReference

Capacity57.9 LReference

Pressure195.1 barReference

Valves2 to 3Reference

Pump flow66.6 lpmReference

Steering flow26.1 lpmReference

Rear TypeIIReference

Controlmechanical lower linkReference

Rear lift (at 24"/610mm)3084 kgReference

Rear PTOindependentReference

Clutchdry discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2100Reference

Engine RPM1000@2100Reference

Power at rated PTO speed74.1 kWReference

Capacities

Fuel157.8 LReference

Front axle6.5 LReference

Front hubs2.0 LReference

Fuel tank157.9 LReference

Crankcase oil volume15.85 qtsReference

Dimensions

Wheelbase234 cmReference

Weight7495 to 9390 poundsReference

Front tire10.00-16Reference

Rear tire18.4-34 (2WD)Reference

Standard tires (ag)Front: 10.00-16. Rear: 18.4-34 (2WD)Reference

Standard tires (ag)Front: 13.6-24. Rear: 18.4-34 (4WD)Reference

Optional tires (ag)Front: 10.00-16. Rear: 18.4-38 (2WD)Reference

2WD Length427 cmReference

4WD Length421 cmReference

Width182 cmReference

Height (cab)273 cmReference

Height (exhaust)269 cmReference

2WD Clearance (front axle)59 cmReference

4WD Clearance (front axle)45 cmReference

Rear axle1828 mmReference

Front tread153 to 204 cmReference

Front tread151 to 201 cmReference

Rear tread151/161/171/181/191/201 cmReference

3399 kgReference

3701 kgReference

3959 kgReference

4259 kgReference

Operating4154 kgReference

Ballasted5599 kgReference

John Deere 6115D attachments

front-end loaderReference

6115D Serial Number Location

Serial number plate on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps70 (ROPS)Reference

Charging amps90 (cab)Reference

Battery CCA925Reference

Battery volts12Reference

Battery AH180Reference

Battery Group31Reference

Total cold cranking amps925 AmpsReference

Attachment overview

John Deere 563 loaderReference

John Deere 673 loaderReference

Test results

Diesel 9-speed 4WDJune 15 - 19, 2009Link: OCED Tractor Test 1949 fileReference

PTO performanceReference

Fuel use23.8 l/hourReference

Drawbar performanceReference

Max pull4470 kgReference

Speeds

With 18.4-34 rear tires.Reference

General

Make & ModelJohn DeereReference

Differential lockmechanical rear | limited-slip front differential (4WD)Reference

SCV controlJoystickReference

Drawbar categoryCat. IIReference

Rollover protective structureTwo-post foldable ROPS.Reference

Country of manufacturerMexicoReference

Hydraulics

Capacity Valves16 valveReference

Hydraulics Typeopen centerReference

Maximum operating pressure2,828 psiReference

Remote Valves2 to 3 ValvesReference

Steering & Implements flow6.9 gpm (20 gpm)Reference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch Sensing Typeposition control | draft-control optionalReference

PTO

PTO Power95 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Engine Speed on Rear PTO speed1,000@2,067 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Dimensions & weight

Height Over Cab274.3 cmReference

Overall Length428 cmReference

Overall Width245.1 cmReference

Front axle clearance59.7 cmReference

Overall weight4,150.4 kgReference

Rear Axle Length182.9 cmReference

Wheels & tyres

Rear Wheel Type18.4-34Reference

Rear wheel tread range201.7 cmReference

Front Wheel Type10.00-16Reference

Front Wheel tread range60.4 to 80.4 inchesReference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
