Tractor · 2013Unverified
John Deere 6115M
John Deere 6115M — 6M Series · 115 hp. Reference specifications; pending source verification.
The John Deere 6115M is a tractor with a power rating of approximately 115 hp, which falls within the mid-range for its class. It was manufactured between 2013 and 2015. The tractor features a 4-cylinder turbocharged intercooled diesel engine, liquid-cooled, and is equipped with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 5210 kg, suitable for operations covering 200-800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Max power
81.0 kW
Weight
5210 kg
Catalogue coverage
Variants represented
2
Richest spec table
142 rows
Recorded power
115 hp
Recorded weight
5210 kg
Transmissions
12-speed fully synchronized
Production years
2013-2015
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Original price$68,644 (2014 SyncroPlus ROPS 2WD )Reference
Original price$95,721 (2014 AutoQuad Cab 4WD )Reference
Two- or four-wheel driveReference
Differential lockElectro-hydraulic rearReference
Differential locklimit-slip front (4WD)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning. GreenStar (optional); AutoTrac (optional)Reference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine (gross)85.8 kWReference
Engine (max)88.7 kWReference
Drawbar (tested)67.5 kWReference
John Deere PowerTech PVXReference
variable geometry turbocharger with intercooler dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
EmissionsInterim Tier IVReference
Emission controlcooled exhaust gas recirculationReference
Rated Power (gross)85.8 kWReference
Maximum Power (gross)88.7 kWReference
Fuel systemhigh pressure common railReference
Compression16.1:1Reference
Rated RPM2100Reference
Torque518.0 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity16.0 LReference
Coolant capacity22.1 LReference
Max power81.0 kWReference
Power at rated engine speed1566.7 kWReference
Max power67.5 kWReference
Fuel TypeDieselReference
No of Cylinders4 cylinderReference
Emissions complianceInterim Tier IV | cooled exhaust gas recirculationReference
Engine torque at rated speed173.3 kgReference
Bore and stroke4.19x5.00 inchesReference
Compression ratio16.1:1Reference
Cooling systemliquid-cooledReference
Transmission
12-speed fully synchronizedReference
16-speed partial power shiftReference
24-speed partial power shiftReference
TransmissionSyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Clutchwet discReference
TransmissionPowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Oil capacity52.1 LReference
TransmissionPowrQuad PlusReference
Gears24 forward and reverseReference
TransmissionAutoQuad PlusReference
Transmission TypeSync ShuttleReference
Wheel Drive4WDReference
Rear Axle Drive Type3 Planetary gear reductionReference
PTO & Hydraulics
PTO (claimed)70.8 kWReference
PTO (tested)1566.7 kWReference
Hydraulic system51.9 LReference
Typeopen center pressure compensatedReference
Typeclosed center load sensing pressure and flow compensated (optional)Reference
Capacity51.9 LReference
Pressure200.0 barReference
Rear valves1 to 3Reference
Mid valves2 or 3 (optional)Reference
Pump flow79.9 lpmReference
Pump flow113.6 lpmReference
SCV flow79.9 lpmReference
Rear TypeII/IIINReference
Controlelectrohydraulic load sensingReference
Rear lift (at 24"/610mm)2337 kgReference
Rear lift (at 24"/610mm)2833 kgReference
DrawbarCat. IIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1932Reference
Engine RPM1000@1932Reference
Power at rated PTO speed78.5 kWReference
Capacities
Fuel219.5 LReference
Fuel tank219.6 LReference
Crankcase oil volume16.9 qtsReference
Dimensions
Wheelbase258 cmReference
Weight5210 kgReference
Front tire10.00-16Reference
Rear tire460/85R34 (2WD)Reference
Standard tires (ag)Front: 10.00-16. Rear: 460/85R34 (2WD)Reference
Standard tires (ag)Front: 380/85R24. Rear: 460/85R34 (4WD)Reference
Max weight8700 kgReference
Clearance (front axle)51 cmReference
Flange rear axleReference
Bar rear axle78 by 2555 mmReference
Front tread153 to 204 cmReference
John Deere 6115M attachments
front-end loaderReference
6115M Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Charging amps150 (optional)Reference
Charging volts14Reference
Battery volts12Reference
Attachment overview
John Deere H310 loaderReference
John Deere H310 MSL loaderReference
John Deere H340 loaderReference
John Deere H340 MSL loaderReference
Test results
Diesel 24-speed PowrQuad Plus 4WDOctober 31 - November 15, 2013Link: OCED Tractor Test 2077 fileReference
PTO performanceReference
Fuel use24.6 l/hourReference
Fuel use17325.1 l/hourReference
Drawbar performanceReference
Fuel use23.8 l/hourReference
Max pull4757 kgReference
General
Make & ModelJohn DeereReference
Drawbar categoryCat. IIReference
Rear Axle TypeFlange | BarReference
Rollover protective structureTwo-post foldable ROPSReference
DisplayPerformance Monitor, Several Settings can be adjustedReference
RadioRadio Available ex factoryReference
Country of manufacturerGermanyReference
Power
Rated Power115 hpReference
PTO
PTO Power95 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM1,000 RPMReference
Engine Speed on Rear PTO speed1,000@1,932 RPMReference
Steering & brakes
Brakeshydraulic wet discReference
Steering typehydrostatic powerReference
Hydraulics
Maximum operating pressure2,900 psiReference
Remote Valves1 to 3 valvesReference
Rear Hitch category (SAE designation)Category II/IIINReference
Rear Hitch Sensing Typeelectrohydraulic load sensingReference
Dimensions & weight
Front axle clearance52 cmReference
Overall weight5,210 kgReference
Wheels & tyres
Rear Wheel Typestd - 460/85R34 (2WD) |opt - 460/85R34 (4WD)Reference
Front Wheel Typestd - 10.00-16 (2WD) | opt - 380/85R24. (4WD)Reference
Front Wheel tread range60.4 to 80.4 (2WD) inchesReference
Operator station
Cab AvailabilityAvailableReference
Cab Air conditioning, temperature differentialTRUEReference
Cab glass area4.79 mReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
