Tractor · 2013Unverified

John Deere 6140M

Name: John Deere 6140M
Brand: John Deere

John Deere 6140M — 6M Series · 140 hp. Reference specifications; pending source verification.

The John Deere 6140M is a tractor with a rated power output of approximately 140 hp, positioning it at the high end of its class. It was manufactured between 2013 and 2015. The tractor features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. It has an operating weight of 5533 kg and is suited to operations on areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

140 hp

Max power

92.5 kW

Weight

5533 kg

Catalogue coverage

Variants represented

Richest spec table

151 rows

Recorded power

140 hp

Recorded weight

5533 kg

Transmissions

16-speed partial power shift

Production years

2013-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Original price$88,344 (2014 PowrQuad 16 ROPS 2WD )Reference

Original price$111,429 (2014 AutoQuad Cab 4WD )Reference

Two- or four-wheel driveReference

Differential lockElectro-hydraulic rearReference

Differential locklimit-slip front (4WD)Reference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-conditioning. GreenStar (optional); AutoTrac (optional)Reference

Engine

John Deere 4.5L 4-cyl dieselReference

Engine (gross)104.4 kWReference

Engine (max)108.1 kWReference

Drawbar (tested)81.1 kWReference

John Deere PowerTech PVXReference

variable geometry turbocharger with intercooler dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke106 x 127 mmReference

EmissionsInterim Tier IVReference

Emission controlcooled exhaust gas recirculationReference

Rated Power (gross)104.4 kWReference

Maximum Power (gross)108.1 kWReference

Fuel systemhigh pressure common railReference

Compression16.1:1Reference

Rated RPM2100Reference

Torque631.9 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity16.0 LReference

Coolant capacity27.4 LReference

Max power92.5 kWReference

Power at rated engine speed86.4 kWReference

Max power81.1 kWReference

Fuel TypeDieselReference

No of Cylinders4Reference

Emissions complianceStage VReference

Engine torque at rated speedOption 1: 2,100 rpm\\nOption 2: 656 NmReference

Interval for engine oil change500 hoursReference

Interval for engine coolant change6,000 hoursReference

Cooling system22 LReference

Transmission

16-speed partial power shiftReference

24-speed partial power shiftReference

TransmissionPowrQuadReference

Typepartial power shiftReference

Gears16 forward and reverseReference

Clutchwet discReference

Oil capacity52.1 LReference

Gears24 forward and reverseReference

TransmissionPowrQuad PlusReference

TransmissionAutoQuad PlusReference

Transmission TypePower QuadReference

Wheel DriveMFWDReference

Rear Axle Drive TypeThree planetary gear reductionReference

Interval for hydraulic/transmission oil change1,500 hoursReference

PTO & Hydraulics

PTO (claimed)85.0 kWReference

PTO (tested)92.5 kWReference

Hydraulic system51.9 LReference

Typeopen center pressure compensatedReference

Typeclosed center load sensing pressure and flow compensated (optional)Reference

Capacity51.9 LReference

Pressure200.0 barReference

Rear valves1 to 3Reference

Mid valves2 or 3 (optional)Reference

Pump flow79.9 lpmReference

Pump flow113.6 lpmReference

SCV flow79.9 lpmReference

Rear TypeII/IIINReference

Controlelectrohydraulic load sensingReference

Rear lift (at 24"/610mm)3006 kgReference

Rear lift (at 24"/610mm)3370 kgReference

DrawbarCat. IIReference

Rear PTOindependentReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1932Reference

Engine RPM1000@1932Reference

Power at rated PTO speed91.7 kWReference

Capacities

Fuel344.4 LReference

Fuel tank195 LReference

Diesel exhaust fluid (DEF) tank13 LReference

Crankcase oil volume4.2 U.S. galReference

Dimensions

Wheelbase276 cmReference

Weight5533 kgReference

Front tire10.00-16Reference

Rear tire460/85R38 (2WD)Reference

Standard tires (ag)Front: 10.00-16. Rear: 460/85R38 (2WD)Reference

Standard tires (ag)Front: 380/85R28. Rear: 460/85R38 (4WD)Reference

Max weight9800 kgReference

Clearance (front axle)51 cmReference

Flange rear axleReference

Bar rear axle85 by 2550 mmReference

Front tread153 to 204 cmReference

John Deere 6140M attachments

front-end loaderReference

6140M Serial Number Location

Serial number plate on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Charging amps150 (optional)Reference

Charging volts14Reference

Battery volts12Reference

Alternator size14 V/120 ampReference

Battery optionsStandard: 12 V/154 amp-hr\\nOptional: 12 V/174 amp-hrReference

Attachment overview

John Deere H340 loaderReference

John Deere H360 loaderReference

Test results

Diesel 24-speed PowrQuad Plus 4WDOctober 24 - November 8, 2013Link: OCED Tractor Test 2079 fileReference

PTO performanceReference

Fuel use26.9 l/hourReference

Fuel use1025.0 l/hourReference

Fuel use27.3 l/hourReference

Drawbar performanceReference

Max pull5261 kgReference

General

Make & ModelJDXL06.8,324Reference

CreeperOptionalReference

SCV controlJoystick: Mechanical/electricalReference

Drawbar categoryCategory 2Reference

Drawbar Maximum vertical load2,000 kgReference

Rear Axle Differential LockElectrohydraulically with oil-cooled clutchReference

Front Axle Differential LockSelf-locking differentialReference

Rollover protective structureGearshift location - console/floor\\nConsoleReference

RadioOptional integratedReference

Country of manufacturerGermanyReference

Power

Rated Power140 hpReference

Power boost10 percentReference

Front Hitch Electric PowerSeven-pin electrical socketReference

PTO

PTO Power110 hpReference

PTO torque rise40 percentReference

Rear PTO PowerAvailableReference

Rear PTO ControlIn-cab switch and external fender-mounted remote controlReference

Rear PTO RPM540/540E/1,000 rpmReference

Front PTO PowerAvailableReference

Engine Speed on Front PTO speed1,969 rpmReference

Hydraulics

Pump Rated Output (total)114 l/minReference

Remote Valves7Reference

Number of rear selective control valves (SCVs)fourReference

Rear Hitch category (SAE designation)2/3NReference

Rear Hitch Sensing TypeElectronic lower linkReference

Front Hitch category (SAE designation)3NReference

Front Hitch lift capacity beyond lift points4,400 kg\\n9,700.3 lbReference

Dimensions & weight

Overall Width1,680 mmReference

Overall weight6,199.7 kgReference

Wheels & tyres

Rear Wheel Type600/65R38 (175)Reference

Operator station

Cab AvailabilityAvailableReference

Cab Noise level70 dBAReference

Cab glass area52.2 sq ftReference

Cab space96.41 cu ftReference

Cab Seat TypeStandard seatReference

Seat SuspensionAvailableReference

Steering & brakes

Steering typeDynamic load sensing, hydrostatic, flow meteringReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
