Tractor · 2013Unverified
John Deere 6150M
John Deere 6150M — 6M Series · 150 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
150 hp
Max power
102.3 kW
Weight
5929 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Original price$95,976 (2014 PowrQuad 16 ROPS 2WD )Reference
Original price$120,645 (2014 AutoQuad Cab 4WD )Reference
Two- or four-wheel driveReference
Differential lockElectro-hydraulic rearReference
Differential locklimit-slip front (4WD)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post foldable ROPS. Cab optional with air-conditioning. GreenStar (optional); AutoTrac (optional)Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Engine (gross)111.9 kWReference
Engine (max)116.3 kWReference
Drawbar (tested)84.4 kWReference
John Deere PowerTech PVXReference
variable geometry turbocharger with intercooler dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
EmissionsInterim Tier IVReference
Emission controlcooled exhaust gas recirculationReference
Rated Power (gross)111.9 kWReference
Maximum Power (gross)116.3 kWReference
Fuel systemhigh pressure common railReference
Compression16.5:1Reference
Rated RPM2100Reference
Torque676.6 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity23.5 LReference
Coolant capacity27.4 LReference
Max power102.3 kWReference
Power at rated engine speed92.8 kWReference
Max power84.4 kWReference
Transmission
16-speed partial power shiftReference
20-speed partial power shiftReference
TransmissionPowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Clutchwet discReference
Oil capacity60.0 LReference
Gears20 forward and reverseReference
TransmissionPowrQuad PlusReference
TransmissionAutoQuad PlusReference
PTO & Hydraulics
PTO (claimed)91.7 kWReference
PTO (tested)102.3 kWReference
Hydraulic system59.8 LReference
Typeclosed center load sensing pressure and flow compensatedReference
Capacity59.8 LReference
Pressure200.0 barReference
Rear valves1 to 3Reference
Mid valves2 or 3 (optional)Reference
Pump flow113.6 lpmReference
SCV flow99.9 lpmReference
Rear TypeIII/IIINReference
Controlelectrohydraulic load sensingReference
Rear lift (at 24"/610mm)4075 kgReference
Rear lift (at 24"/610mm)4599 kgReference
DrawbarCat. IIReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1932Reference
Engine RPM1000@1932Reference
Power at rated PTO speed97.9 kWReference
Capacities
Fuel355.8 LReference
Dimensions
Wheelbase276 cmReference
Weight5929 kgReference
Front tire10.00-16Reference
Rear tire460/85R38 (2WD)Reference
Standard tires (ag)Front: 10.00-16. Rear: 460/85R38 (2WD)Reference
Standard tires (ag)Front: 420/85R28. Rear: 460/85R42 (4WD)Reference
Max weight10799 kgReference
Clearance (front axle)51 cmReference
Flange rear axleReference
Bar rear axle85 by 2550 mmReference
Front tread160 to 221 cmReference
John Deere 6150M attachments
front-end loaderReference
6150M Serial Number Location
Serial number plate on the right side of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Charging amps150 (optional)Reference
Charging volts14Reference
Battery volts12Reference
Attachment overview
John Deere H340 loaderReference
John Deere H360 loaderReference
Test results
Diesel 20-speed AutoQuad Plus 4WDOctober 28 - November 14, 2013Link: OCED Tractor Test 2080 fileReference
PTO performanceReference
Fuel use29.5 l/hourReference
Fuel use28.8 l/hourReference
Drawbar performanceReference
Fuel use29.1 l/hourReference
Max pull6066 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
