Tractor · 2015Unverified
John Deere 6155RH
John Deere 6155RH — 6R Series · 155 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
155 hp
Weight
6872 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
High-Clearance tractorReference
Original price was $190,326 in 2021Reference
Four-wheel driveReference
Power steeringReference
Cab standard with air-conditioning.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Fuel tank355.8 LReference
Engine (gross)115.6 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke105 x 127 mmReference
Rated Power (gross)115.6 kWReference
Rated RPM2100Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed four-speed power shiftReference
TransmissionPowerQuad PLUSReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
Typeclosed centerReference
Rear valves3Reference
Pump flow113.9 lpmReference
Pump flow154.8 lpmReference
Rear TypeIIIReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/540E/1000Reference
Dimensions
Wheelbase276 cmReference
Weight6872 kgReference
Front tire320/90R46Reference
Rear tire18.4R38Reference
Standard tires (ag)Front: 320/90R46. Rear: 18.4R38Reference
Height (cab)317 cmReference
Clearance (front axle)64 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
