Tractor · 2010Unverified

John Deere 6180J

Name: John Deere 6180J
Brand: John Deere

John Deere 6180J — 6J Series · 152 hp. Reference specifications; pending source verification.

The John Deere 6180J is a tractor with a rated power output of 152 hp, positioning it within the higher-powered category of its class. Manufactured in 2010, the 6180J is equipped with a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, which drives four-wheel drive via a powershift transmission. The listed weight of the tractor ranges from 15860 to 16480 pounds. It is designed to handle jobs of approximately 200–800 acres in size.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

152 hp

Weight

15860 to 16480 pounds

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

152 hp

Transmissions

16-speed partial power shift

Production years

2010-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Montenegro, BrazilReference

Four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Hydraulic wet disc brakesReference

Four-post ROPS. Cab optional.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank300.0 LReference

Engine134.2 kWReference

John Deere 6068 PowerTechReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Power134.2 kWReference

Fuel systemrotary injection pumpReference

Rated RPM2100Reference

Torque722.1 NmReference

Torque RPM1400Reference

Starter volts12Reference

Transmission

16-speed partial power shiftReference

TransmissionJohn Deere PowrQuadReference

Typepartial power shiftReference

Gears16 forward and reverseReference

Clutchhydraulic wet discsReference

Oil typeJD Hy-GardReference

Four power shift gears (1-4) in four synchronized ranges (A-D).Reference

PTO & Hydraulics

PTO (claimed)113.3 kWReference

Typeclosed center pressure-flow compensated (PFC)Reference

Pressure200.0 barReference

Valves2 to 3Reference

Pump flow110.0 lpmReference

SCV flow105.0 lpmReference

Oil typeJD Hy-GardReference

Rear TypeIIIReference

Controlelectronic lower linkReference

Rear lift (at ends)6001 kgReference

Rear lift (at 24"/610mm)5801 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase273 cmReference

Weight15860 to 16480 poundsReference

Front tire16.9-28Reference

Rear tire20.8-38Reference

Standard tires (ag)Front: 16.9-28. Rear: 20.8-38Reference

Optional tires (ag)Front: 18.4-26. Rear: 24.5-32Reference

Optional tires (ag)Front: 16.9R30. Rear: 20.8R42Reference

Optional tires (ag)Front: 18.4-26. Rear: 30.5-32Reference

Optional tires (ag)Front: 480/70R28. Rear: 650/75R32Reference

Length542 cmReference

Height293 cmReference

Ground clearance52 cmReference

Rear axle92 by 2405 mmReference

Rear axle92 by 2776 mmReference

Front tread142 to 213 cmReference

Rear tread158 to 321 cmReference

ROPS7194 kgReference

Cab7475 kgReference

Ballasted10351 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Battery volts12Reference

Battery AH150Reference

Speeds

With 20.8-38 R1 rear tires. Reverse speeds are 15% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
