Tractor · 1937Unverified
John Deere 62
John Deere 62 — Utility tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
680 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Moline, Illinois, USAReference
Total built78Reference
Original price$450 (1937)Reference
The John Deere model 62 tractor was resulted from years of research into a small tractor that would replace one or two horses. The 62 replaced the experimental model Y, although the 62 itself became the model L after less than one year of production. The 62 can be readily distinguished from the L by the "JD" below the radiator.Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station with steel pan seat.Reference
Engine
Hercules 0.9L 2-cyl gasolineReference
Engine7.5 kWReference
Hercules NXAReference
gasolineReference
2-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke76 x 102 mmReference
Power7.5 kWReference
Rated RPM1550Reference
Transmission
3-speed unsynchronized gearReference
TransmissionSpicerReference
Typeunsynchronized gearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight680 kgReference
Front tire4x15Reference
Rear tire6x22Reference
Ag front4x15Reference
Ag rear6x22Reference
Length231 cmReference
Width124 cmReference
Height (hood)144 cmReference
Shipping weight680 kgReference
62 Serial Numbers
Location:Right side of rear axleReference
1937621001Reference
Final621078Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
