Tractor · 1993Unverified

John Deere 6200L

Name: John Deere 6200L
Brand: John Deere

John Deere 6200L — Orchard/Vineyard tractor · 66 hp. Reference specifications; pending source verification.

The John Deere 6200L is a tractor with a power rating of approximately 66 hp, falling within the mid-range of its class. Produced between 1993 and 1998, it features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. The operating weight of the 6200L is listed as between 7420 and 7916 pounds. It is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

66 hp

Weight

7420 to 7916 pounds

Catalogue coverage

Variants represented

Richest spec table

79 rows

Recorded power

66 hp

Recorded weight

3365 kg

Transmissions

12-speed fully synchronized

Production years

1993-1998

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Orchard/Vineyard tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Two- or four-wheel driveReference

Power steeringReference

Differential hydraulic wet disc brakesReference

ROPS.Reference

Variants

6200utility tractorReference

6200L[6587]Reference

Engine

John Deere 3.9L 4-cyl dieselReference

Engine61.9 kWReference

John Deere 4039Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke106 x 110 mmReference

Power61.9 kWReference

Compression17.8:1Reference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Starter power3.1 kWReference

Oil capacity12.0 LReference

Coolant capacity11.0 LReference

Transmission

12-speed fully synchronizedReference

21-speedReference

16-speed partial power shiftReference

28-speed partial power shiftReference

TransmissionJohn Deere SyncroPlusReference

Typefully synchronizedReference

Gears12 forward and 4 reverseReference

Oil capacity51.9 LReference

Three gears, plus reverse, in four ranges.Reference

TransmissionJohn Deere SyncroPlus CreeperReference

Gears21 forward and 7 reverseReference

TransmissionJohn Deere PowrQuadReference

Typepartial power shiftReference

Gears16 forward and reverseReference

Oil capacity48.8 LReference

Four power shift gears in four synchronized ranges, with reverser.Reference

TransmissionJohn Deere PowrQuad CreeperReference

Gears28 forward and reverseReference

PTO & Hydraulics

PTO (claimed)49.2 kWReference

Typeclosed center pressure flow compensatedReference

Pressure200.0 barReference

Valves2Reference

Total flow68.1 lpmReference

Total flow96.1 lpmReference

Rear TypeIIReference

Rear lift2152 kgReference

Rear PTO Type540Reference

Rear PTO Type540/1000 (optional)Reference

Capacities

Fuel113.6 LReference

Front axle6.4 LReference

Front hubs3.4 LReference

Dimensions

Wheelbase240 cmReference

Weight7420 to 7916 poundsReference

Front tire27/9.5-15Reference

Rear tire16.9-24Reference

Ag front27/9.5-15 (2WD)Reference

Ag front10.5/80-18 (4WD)Reference

Ag rear16.9-24Reference

Length414 cmReference

Width197 cmReference

Height (steering wheel)169 cmReference

Height (ROPS)229 cmReference

Height (Folded ROPS)169 cmReference

Shipping weight3365 kgReference

Shipping weight3590 kgReference

Ground clearance32 cmReference

John Deere 6200L attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery CCA780Reference

Battery volts12Reference

Battery AH110Reference

Battery AH154 (optional)Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
