Tractor · 1999Unverified

John Deere 6210

John Deere 6210 — Utility tractor · 90 hp. Reference specifications; pending source verification.

The John Deere 6210 is a tractor with a rated output of 90 hp, situated at a mid-point within its class in terms of power. It was manufactured from 1999 to 2002 and features a 4-cylinder turbocharged diesel liquid-cooled engine. This engine powers a four-wheel drive system with a powershift transmission. The tractor's listed weight ranges from 7420 to 9610 pounds, and it is designed for use in areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
90 hp
Max power
58.6 kW
Weight
7420 to 9610 pounds

Catalogue coverage

Variants represented
2
Richest spec table
122 rows
Recorded power
90 hp
Transmissions
12-speed fully synchronized
Production years
1999-2002
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulicReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Two-post ROPS. ComfortGard cab optional with air-conditioning.Reference

Variants

6210utility tractorReference
6210Llow-profileReference
6210Slow-profile cabReference

Engine

John Deere 4.5L 4-cyl dieselReference
Fuel tank116.2 LReference
Fuel tank165.0 LReference
Engine (gross)67.1 kWReference
Drawbar (tested)46.1 kWReference
John Deere 4045TL054Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power (gross)67.1 kWReference
Compression17.8:1Reference
Rated RPM2300Reference
Operating RPM1500-2300Reference
Torque371.5 NmReference
Torque RPM1900Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity12.0 LReference
ROPS Coolant capacity11.0 LReference
Cab Coolant capacity13.5 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Max power58.6 kWReference
Power at rated engine speed55.7 kWReference
Max power46.1 kWReference

Transmission

12-speed fully synchronizedReference
16-speed four-speed power shiftReference
24-speed four-speed power shiftReference
TransmissionSyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Clutchwet discReference
Three gears (1-3), plus reverse (R) in four ranges (A-D).Reference
TransmissionSyncroPlus Power ReverserReference
Typefour-speed power shiftReference
Gears16 forward and reverseReference
Four synchronized gears (1-4) in four ranges (A-D) with left-hand power reverser.Reference
TransmissionPowrQuadReference
Clutchhydraulic wet discReference
Four power shift gears (1-4) in four synchronized ranges (A-D) with reverser.Reference
Gears24 forward and reverseReference
Four power shift gears (1-4) in six synchronized ranges (A-F) with reverser.Reference

PTO & Hydraulics

PTO (claimed)53.7 kWReference
PTO (tested)58.6 kWReference
Typeclosed center pressure-flow compensatingReference
Pressure200.0 barReference
Valves1 to 4Reference
Pump flow96.1 lpmReference
Pump flow71.5 lpmReference
Rear TypeIIReference
Controlelectronic lower-link draft sensingReference
Rear lift2152 kgReference
Front HitchoptionalReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2143Reference
Engine RPM540E@1684Reference
Engine RPM1000@2208Reference
Front PTOindependentReference
Front PTO Type1000Reference
Engine RPM1000@2185Reference
Power at rated PTO speed56.7 kWReference

Dimensions

Wheelbase240 cmReference
Weight7420 to 9610 poundsReference
Front tire7.50-18Reference
2WD Rear tire16.9-30Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 16.9-30Reference
4WD Standard tires (ag)Front: 12.4-24. Rear: 16.9-30Reference
Length413 cmReference
Width203 cmReference
2WD Clearance (front axle)58 cmReference
4WD Clearance (front axle)46 cmReference
Flange rear axleReference
Rack-and-pinion rear axle78 by 2268 mmReference
Rack-and-pinion rear axle78 by 2555 mmReference
2WD ROPS Shipping3365 kgReference
2WD Cab Shipping3595 kgReference
4WD ROPS Shipping3590 kgReference
4WD Cab Shipping3820 kgReference
4WD Cab Operating4359 kgReference
Steering wheel176 cmReference

John Deere 6210 attachments

front-end loaderReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps90Reference
Cab Charging amps115Reference
Battery CCA830Reference
Battery CCA1230Reference
Battery volts12Reference
Battery AH110Reference
Battery AH154Reference

Attachment overview

John Deere 620 loaderReference
John Deere 640 loaderReference
John Deere 640SL loaderReference

John Deere 6210 Height

ROPS273 cmReference
Cab258 cmReference
Exhaust256 cmReference

Test results

Diesel PowrQuad 4WDJune 1998 - October 1998, Link: OCED Tractor Test 1821 fileReference
PTO performanceReference
Fuel use17.0 l/hourReference
Fuel use18.2 l/hourReference
Drawbar performanceReference
Gear 3B used for power test.Reference
Max pull4851 kgReference
Gear 1B used for pull test.Reference

Speeds

With 18.4-30 rear tires.Reference
With 18.4-30 rear tires. Reverse speeds are 20% faster than forward.Reference
