Tractor · 2007Unverified
John Deere 6230
John Deere 6230 · 95 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
95 hp
Weight
8582 to 10515 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Original price$49,565 (2010)Reference
Two- or four-wheel driveReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Variants
6230 Premiumpremium cab and upgraded featuresReference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine (gross)70.8 kWReference
John Deere 4045HL280 PowerTech EReference
turbocharged dieselReference
4-cylinder 8-valveReference
liquid-cooled vertical inlineReference
Original engine, used in the basic 6230 from 2007 through the 2009 model year.Reference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
EmissionsTier IIIReference
Rated Power (gross)70.1 kWReference
Air cleanerdual dry elementReference
Compression19:1Reference
Rated RPM2300Reference
Idle RPM850-2460Reference
Operating RPM1500-2300Reference
Torque382.4 NmReference
Torque RPM1500Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity15.9 LReference
Coolant capacity26.5 LReference
Coolant capacity29.1 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
John Deere 4045HL287 PowerTech EReference
Replacement engine, first used in the 2010 model year.Reference
Rated Power (gross)70.8 kWReference
Torque383.7 NmReference
Torque RPM1600Reference
Transmission
12-speed fully synchronizedReference
16-speed synchronized with power shuttleReference
16-speed partial power shiftReference
24-speed partial power shiftReference
TransmissionJohn Deere SyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Oil capacity51.9 LReference
TransmissionJohn Deere PowrReverserReference
Typesynchronized with power shuttleReference
Gears16 forward and reverseReference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Clutchwet discReference
Oil capacity48.8 LReference
Oil capacity50.0 LReference
Four gears (1-4) in four ranges (A-D) with left-hand reverser lever. Gear changes (1-4) and direction changes can be done while moving without the clutch. Clutch is required to shift range (A-D). Optional PowrQuad Plus adds push-button gear shifting.Reference
Gears24 forward and reverseReference
Oil capacity50.0 LReference
Four gears (1-4) in six ranges (A-E) with left-hand reverser lever. Gear changes (1-4) and direction changes can be done while moving without the clutch. Clutch is required to shift range (A-D). Optional PowrQuad Plus adds push-button gear shifting.Reference
PTO & Hydraulics
PTO (claimed)55.9 kWReference
PTO (claimed)56.7 kWReference
Hydraulic system51.9 LReference
Typeopen-center load sensingReference
Typeclosed-center pressure-flow compensated (optional)Reference
Capacity51.9 LReference
Pressure200.0 barReference
Valves1 to 3Reference
Total flow79.9 lpmReference
Total flow109.8 lpmReference
Rear TypeII/IIIReference
Rear lift (at 24"/610mm)2018 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Capacities
Fuel165.0 LReference
Fuel181.7 LReference
Max capacity7600 kgReference
Dimensions
Wheelbase240 cmReference
Weight8582 to 10515 poundsReference
Front tire12.4R24Reference
Rear tire18.4R30Reference
Ag front12.4R24Reference
Ag rear18.4R30Reference
Ground clearance46 cmReference
Shipping3892 kgReference
Shipping4076 kgReference
Shipping4389 kgReference
Operating4769 kgReference
Max Drawbar2249 kgReference
Max front axle2050 kgReference
Max front axle5000 kgReference
Max front axle3699 kgReference
Max front axle5499 kgReference
6230 Serial Number Location
On the main tractor frame, right side, above the front axle.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps115Reference
Battery volts12Reference
Speeds
With 18.4R38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
