Tractor · 1999Unverified

John Deere 6310S

Name: John Deere 6310S
Brand: John Deere

John Deere 6310S — Orchard/Vineyard tractor · 99 hp. Reference specifications; pending source verification.

The John Deere 6310S is a tractor model with a rated power output of 99 horsepower, a figure within its mid-range class. It was manufactured between 1999 and 2002. The tractor is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a powershift transmission. Its operating weight is listed as 8077 to 8554 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

99 hp

Weight

8077 to 8554 pounds

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

99 hp

Recorded weight

3663 kg

Transmissions

12-speed fully synchronized

Production years

1999-2002

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Orchard/Vineyard tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Two- or four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard.Reference

Variants

6310utility tractorReference

6310Llow-profile ROPSReference

6310Slow-profile cabReference

Engine

John Deere 4.5L 4-cyl dieselReference

Fuel tank165.0 LReference

Engine (gross)73.8 kWReference

John Deere 4045Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke106 x 127 mmReference

Power (gross)73.8 kWReference

Rated RPM2300Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Starter power3.0 kWReference

Coolant capacity13.6 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Oil capacity12.1 LReference

Transmission

12-speed fully synchronizedReference

16-speed power shuttleReference

16-speed partial power shiftReference

38-speed four-speed power shiftReference

TransmissionJohn Deere SyncroPlusReference

Typefully synchronizedReference

Gears12 forward and 4 reverseReference

Oil capacity51.9 LReference

Oil type[30oC]Reference

-10oF [-23oC]↑: JD HY-GARDReference

86oF [30oC]↓: Low-Visocosity HY-GARDReference

Three gears, plus reverse, in four ranges.Reference

TransmissionJohn Deere SyncroPlus Power ReverserReference

Typepower shuttleReference

Gears16 forward and reverseReference

Four synchronized gears, plus reverse, in four ranges with power shuttle.Reference

TransmissionJohn Deere PowrQuadReference

Typepartial power shiftReference

Oil capacity48.8 LReference

Four power shift gears in four synchronized ranges, with reverser.Reference

TransmissionPowrQuad CreeperReference

Typefour-speed power shiftReference

Gears38 forward and reverseReference

Creeper option adds an additional low-speed for ranges A, B, and C.Reference

PTO & Hydraulics

PTO (claimed)59.7 kWReference

Typeclosed center load sensingReference

Pressure200.0 barReference

Valves1 to 4Reference

Pump flow96.1 lpmReference

Pump flow71.5 lpmReference

Rear TypeIIReference

Controlelectronic lower-link draft sensingReference

Rear lift2222 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Rear PTO Type540/1000 (1.375)Reference

Dimensions

Wheelbase240 cmReference

Weight8077 to 8554 poundsReference

Front tire27/9.5-15Reference

2WD Rear tire16.9-24Reference

2WD Standard tires (ag)Front: 27/9.5-15. Rear: 16.9-24Reference

4WD Standard tires (ag)Front: 10.5/80-18. Rear: 16.9-24Reference

Length413 cmReference

Height (cab)239 cmReference

2WD Shipping weight3663 kgReference

4WD Shipping weight3880 kgReference

6310S Serial Numbers

Location:Main tractor frame on right side.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps115Reference

Battery CCA850Reference

Battery CCA1230Reference

Battery volts12Reference

Battery AH110Reference

Battery AH154Reference

Speeds

With 18.4-30 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
