Tractor · Unverified

John Deere 6325

Name: John Deere 6325
Brand: John Deere

John Deere 6325 — Utility tractor · 105 hp. Reference specifications; pending source verification.

The John Deere 6325 is a tractor with a rated power output of approximately 105 hp, falling within the mid-range for its class. It features a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with mechanical front-wheel drive and a hydrostatic transmission. The tractor has an operating weight of 3779 kg. It is suitable for operations covering 200-800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Weight

3779 kg

Catalogue coverage

Variants represented

Richest spec table

79 rows

Recorded power

105 hp

Recorded weight

3779 kg

Transmissions

12-speed synchronized

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD (optional)Reference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

John Deere 4.5L 4-cyl dieselReference

Fuel tank165.0 LReference

Engine (gross)78.3 kWReference

Engine (net)74.6 kWReference

Engine (max)81.3 kWReference

John Deere 4045HLReference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.5 LReference

Bore/Stroke106 x 127 mmReference

EmissionsStage IIIReference

Rated Power (net)74.6 kWReference

Rated Power (gross)78.3 kWReference

Maximum Power (net)78.3 kWReference

Maximum Power (gross)81.3 kWReference

Fuel systemelectronic fuel injectionReference

Cooling systemviscous fanReference

Rated RPM2300Reference

Idle RPM850-2460Reference

Operating RPM1500-2300Reference

Torque432.6 NmReference

Torque RPM1600Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Oil capacity16.0 LReference

Coolant capacity26.5 LReference

Transmission

12-speed synchronizedReference

16-speed power shuttleReference

TransmissionJohn Deere SyncroPlusReference

TypesynchronizedReference

Gears12 forward and 4 reverseReference

Clutchwet 225mm disc PermaClutch IIReference

Oil capacity55.0 LReference

Three gears (1-3) plus reverse (R) in four ranges (A-D).Reference

TransmissionJohn Deere PowrReverserReference

Typepower shuttleReference

Gears16 forward and reverseReference

Four gears (1-4) in four ranges (A-D) with left-hand reverser lever. 30 KPH and 40 KPH maximum speed options available.Reference

PTO & Hydraulics

PTO (claimed)65.6 kWReference

Typeopen center gear pumpReference

Pressure175.0 barReference

Pump flow54.0 lpmReference

Rear Type2/1Reference

Controlload and depth control with mechanical top-link sensingReference

Rear lift4099 kgReference

Rear PTOindependentReference

Clutchmechanical-hydraulic wet discReference

Rear PTO Type540/1000Reference

Engine RPM540@2143Reference

Engine RPM1000@2208Reference

Dimensions

Wheelbase240 cmReference

Weight3779 kgReference

Front tire7.50R18Reference

Rear tire18.4R30 (2WD)Reference

Standard tires (ag)Front: 7.50R18. Rear: 18.4R30 (2WD)Reference

Standard tires (ag)Front: 13.6R24. Rear: 18.4R30 (4WD)Reference

Length427 cmReference

Width221 cmReference

Height (ROPS)276 cmReference

Shipping weight3779 kgReference

Max weight6999 kgReference

Clearance (rear axle)161 cmReference

Flange rear axleReference

6325 Serial Numbers

Location:Right side of main tractor frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Battery volts12Reference

Battery AH110Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
