Tractor · 1998Unverified
John Deere 6405
John Deere 6405 — Advantage Series · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Weight
7695 to 8987 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Original price was $35,000 in 1999Reference
The 6405 was one of the Advantage Series tractors designed to provide an economical alternative to the full-features on the TEN series tractors. Transmission options, hydraulics, and the cab were the major differences between the two models.Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS. Advantage Cab optional with air-conditioning.Reference
Variants
6410TEN seriesReference
6405Advantage seriesReference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank165.0 LReference
Fuel tank116.2 LReference
John Deere 4045Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Air cleanerdry dual elementReference
Compression17.8:1Reference
Rated RPM2300Reference
Idle RPM875-2510Reference
Operating RPM1000-2300Reference
Torque432.6 NmReference
Torque RPM1400Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity12.0 LReference
ROPS Coolant capacity11.0 LReference
Cab Coolant capacity13.5 LReference
Intake valve clearance0.457 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
12-speed fully synchronizedReference
16-speed power shuttleReference
TransmissionJohn Deere SyncroVantageReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Oil capacity51.9 LReference
Three gears (1-3) plus reverse (R) with four ranges (A-D).Reference
TransmissionJohn Deere SyncroVantage Power ReverserReference
Typepower shuttleReference
Gears16 forward and reverseReference
Four gears (1-4) in four ranges (A-D) with left-hand reverser lever. Power shuttle allows direction changes without using the clutch.Reference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
Typeconstant-flow load-sensingReference
Pressure172.4 barReference
Valves2 to 4Reference
Total flow66.2 lpmReference
Rear TypeIIReference
Controlposition control with optional draft controlReference
Rear lift2280 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2143Reference
Engine RPM1000@2208Reference
Dimensions
Wheelbase240 cmReference
Weight7695 to 8987 poundsReference
Front tire10.00-16Reference
Rear tire18.4-34 (2WD)Reference
Standard tires (ag)Front: 10.00-16. Rear: 18.4-34 (2WD)Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-34 (4WD)Reference
Standard tires (ag)Front: 13.6-38. Rear: 13.6-46 (High Clearance)Reference
Length413 cmReference
Flange rear axleReference
Rear tread151/161/171/181/191 cmReference
2WD ROPS Shipping3490 kgReference
4WD ROPS Shipping3687 kgReference
2WD cab Shipping3891 kgReference
4WD cab Shipping4076 kgReference
2WD Max Drawbar1399 kgReference
4WD Max Drawbar1598 kgReference
4WD Max Drawbar800 kgReference
Max rear axle5599 kgReference
Steering wheel182 cmReference
6405 Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.Reference
1998206000Reference
1999233700Reference
2000260600Reference
2001322099Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps90Reference
Battery CCA830Reference
Battery volts12Reference
Capacities
Max capacity6999 kgReference
John Deere 6405 Height
ROPS280 cmReference
Exhaust246 cmReference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
