Tractor · 1999Unverified
John Deere 6410S
John Deere 6410S — Orchard/Vineyard tractor · 104 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
104 hp
Weight
8152 to 8788 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard.Reference
Variants
6410utlity tractorReference
6410Llow-profileReference
6410Slow-profile cabReference
Engine
John Deere 4.5L 4-cyl dieselReference
Fuel tank165.0 LReference
Engine (gross)77.6 kWReference
John Deere 4045Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power (gross)77.6 kWReference
Rated RPM2300Reference
Torque440.7 NmReference
Torque RPM1400Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Starter power3.0 kWReference
Coolant capacity13.6 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Oil capacity12.1 LReference
Transmission
12-speed fully synchronizedReference
16-speed power shuttleReference
16-speed partial power shiftReference
38-speed four-speed power shiftReference
TransmissionJohn Deere SyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Oil capacity51.9 LReference
Oil type[30oC]Reference
-10oF [-23oC]↑: JD HY-GARDReference
86oF [30oC]↓: Low-Visocosity HY-GARDReference
Three gears, plus reverse, in four ranges.Reference
TransmissionJohn Deere SyncroPlus Power ReverserReference
Typepower shuttleReference
Gears16 forward and reverseReference
Four synchronized gears, plus reverse, in four ranges with power shuttle.Reference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Oil capacity48.8 LReference
Four power shift gears in four synchronized ranges, with reverser.Reference
TransmissionPowrQuad CreeperReference
Typefour-speed power shiftReference
Gears38 forward and reverseReference
Creeper option adds an additional low-speed for ranges A, B, and C.Reference
PTO & Hydraulics
PTO (claimed)67.1 kWReference
Typeclosed center load sensingReference
Pressure200.0 barReference
Valves1 to 4Reference
Pump flow96.1 lpmReference
Pump flow71.5 lpmReference
Rear TypeIIReference
Controlelectronic lower-link draft sensingReference
Rear lift2683 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase240 cmReference
Weight8152 to 8788 poundsReference
Front tire27/9.5-15Reference
2WD Rear tire18.4-26Reference
2WD Standard tires (ag)Front: 27/9.5-15. Rear: 18.4-26Reference
4WD Standard tires (ag)Front: 10.5/80-18. Rear: 18.4-26Reference
Length413 cmReference
Height (cab)244 cmReference
2WD Shipping3697 kgReference
4WD Shipping3986 kgReference
6410S Serial Numbers
Location:Main tractor frame on right side.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps115Reference
Battery CCA850Reference
Battery CCA1230Reference
Battery volts12Reference
Battery AH110Reference
Battery AH154Reference
Capacities
Max capacity7999 kgReference
Speeds
With 18.4-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
