Tractor · 1998Unverified

John Deere 6410SE

Name: John Deere 6410SE
Brand: John Deere

John Deere 6410SE — Utility tractor · 105 hp. Reference specifications; pending source verification.

The John Deere 6410SE is a tractor model with a rated output of 105 hp, placing it in the middle of its class for power. Produced from 1998 to 2003, this model features a 4-cylinder turbocharged diesel liquid-cooled engine, which drives a four-wheel drive system with a powershift transmission. Its listed weight is 4077 kg, and it is suitable for tasks of approximately 200 to 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

105 hp

Weight

4077 kg

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

105 hp

Recorded weight

4077 kg

Transmissions

12-speed synchronized

Production years

1998-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockelectro-hydraulic rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Trailer brakespneumaticReference

Cab standard with heat. Optional air-conditioning.Reference

Engine

John Deere 4.5L 4-cyl dieselReference

Engine (net)78.3 kWReference

John DeereReference

turbocharged dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement4.5 LReference

Bore/Stroke106 x 127 mmReference

Rated Power (net)78.3 kWReference

Cooling systemviscous-drive fanReference

Air cleanerdryReference

Rated RPM2300Reference

Torque429.4 NmReference

Torque RPM1495Reference

StarterelectricReference

Starter volts12Reference

Oil capacity12.0 LReference

Coolant capacity13.5 LReference

Transmission

12-speed synchronizedReference

16-speed power shuttleReference

16-speed four-speed power shiftReference

TransmissionSynchroPlusReference

TypesynchronizedReference

Gears12 forward and 4 reverseReference

Clutch225mm wet discsReference

Oil change250 hReference

Three synchronized gears, plus reverse, in four synchronized ranges.Reference

TransmissionPower ReverserReference

Typepower shuttleReference

Gears16 forward and reverseReference

Four synchronized gears in four synchronized ranges with power shuttle.Reference

TransmissionPowerQuadReference

Typefour-speed power shiftReference

Four power shift gears in four synchronized ranges with power shuttle.Reference

Capacities

Fuel165.0 LReference

Fuel115.8 LReference

PTO & Hydraulics

Hydraulic system54.9 LReference

Typeopen center load-sensingReference

Capacity54.9 LReference

Pressure200.0 barReference

Valves4Reference

Pump flow54.1 lpmReference

Rear TypeIIReference

Controlelectronic lower-link draft sensingReference

Rear lift5363 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2124Reference

Engine RPM1000@2208Reference

Engine RPM540E@1684Reference

Front PTOindependentReference

Front PTO Type1000Reference

Engine RPM1000@2185Reference

Dimensions

Wheelbase240 cmReference

Weight4077 kgReference

Front tire13.6R24Reference

Rear tire16.9R34Reference

Standard tires (ag)Front: 13.6R24. Rear: 16.9R34Reference

Length414 cmReference

Width217 cmReference

Height (cab)264 cmReference

Height (cab)253 cmReference

Shipping weight4077 kgReference

Max weight8000 kgReference

6410SE Serial Numbers

Location:Serial number plate on the right side of the tractor's frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Battery volts12Reference

Battery AH110Reference

Speeds

With 14.9-38 rear tires.Reference

With 14.9-38 rear tires and 30KPH transmission option. Rear speeds are 20% faster than forward.Reference

With 14.9-38 rear tires and 40KPH transmission option. Rear speeds are 20% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
