Tractor · 2001Unverified

John Deere 6520 Premium

Name: John Deere 6520 Premium
Brand: John Deere

John Deere 6520 Premium — Model year 2001-20032003-2006 · 110 hp. Reference specifications; pending source verification.

The John Deere 6520 Premium is a tractor rated at 110 hp, placing it in the middle of its class for power output. Manufactured from 2001 to 2006, it features a 6-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system via a hydrostatic transmission. The listed weight for this tractor is 5080 kg, and it is intended for use on plots of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

110 hp

Weight

5080 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

110 hp

Recorded weight

5080 kg

Transmissions

24-speed partial power shift

Production years

2001-2006

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Utility tractorReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Cab standard.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank207.0 LReference

Engine (net)82.0 kWReference

John Deere 6068Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Rated Power (net)82.0 kWReference

Rated RPM2300Reference

Idle RPM850-2460Reference

Operating RPM1300-2300Reference

Torque462.4 NmReference

Torque RPM1500Reference

Firing order1-5-3-6-2-4Reference

StarterelectricReference

Starter volts12Reference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Transmission

24-speed partial power shiftReference

TransmissionPowrQuad PlusReference

Typepartial power shiftReference

Gears24 forward and reverseReference

TransmissionAutoQuad IIReference

PTO & Hydraulics

PTO (claimed)72.3 kWReference

Typeclosed center load sensingReference

Pressure200.0 barReference

Pump flow96.1 lpmReference

Rear TypeII/IIINReference

Rear lift6618 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Weight5080 kgReference

Front tire16.9R24Reference

Rear tire18.4R38Reference

Standard tires (ag)Front: 16.9R24. Rear: 18.4R38Reference

5080 kgReference

Max front axle3800 kgReference

Max front axle4199 kgReference

Max rear axle6500 kgReference

6520 Premium Serial Numbers

Location:Right side of main tractor frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Charging amps115Reference

Battery volts12Reference

Capacities

Max capacity7994 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
