Tractor · 1993Unverified

John Deere 6800

Name: John Deere 6800
Brand: John Deere

John Deere 6800 — Row-Crop tractor · 120 hp. Reference specifications; pending source verification.

The John Deere 6800 is a tractor model with a power output of 120 hp, positioning it among the more powerful machines in its class. Manufactured from 1993 to 1997, this model features a 6-cylinder turbocharged diesel liquid-cooled engine, which powers four-wheel drive through a powershift transmission. The listed weight of the John Deere 6800 is 4989 kg and it is designed to handle a range of tasks covering approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

120 hp

Weight

4989 kg

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

120 hp

Recorded weight

4989 kg

Transmissions

16-speed partial power shift

Production years

1993-1997

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

Built in Mannheim, Baden-Württemberg, GermanyReference

Four-wheel driveReference

Differential lockelectro-hydraulicReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank207.0 LReference

Engine89.5 kWReference

John Deere 6068Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Power89.5 kWReference

Rated RPM2100Reference

Torque536.0 NmReference

Torque RPM1300Reference

Firing order1-5-3-6-2-4Reference

StarterelectricReference

Starter volts12Reference

Transmission

16-speed partial power shiftReference

20-speed partial power shiftReference

TransmissionJohn Deere PowrQuadReference

Typepartial power shiftReference

Gears16 forward and reverseReference

Clutchwet discReference

Four power shift gears in four ranges, with power shuttle.Reference

Gears20 forward and reverseReference

Four power shift gears (1-4) in five ranges (A-E) with power shuttle. Available in 30 kph and 40 kph versions depending on market.Reference

PTO & Hydraulics

Typeclosed centerReference

Pressure200.0 barReference

Pump flow60.2 lpmReference

Pump flow96.1 lpmReference

Rear TypeII/IIINReference

Rear lift6841 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540E/1000Reference

Engine RPM540E@1754Reference

Engine RPM1000@2000Reference

Front PTOindependentReference

Dimensions

Wheelbase264 cmReference

Weight4989 kgReference

Front tire16.9R26Reference

Rear tire18.8R38Reference

Ag front16.9R26Reference

Ag rear18.8R38Reference

Length455 cmReference

Width236 cmReference

Height (cab)280 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps85Reference

Charging amps120Reference

Battery volts12Reference

Speeds

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
