Tractor · 1994Unverified
John Deere 6900
John Deere 6900 — Row-Crop tractor · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Weight
5391 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Four-wheel driveReference
Differential lockelectro-hydraulicReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Fuel tank250.2 LReference
Engine96.9 kWReference
John Deere 6068Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
Power96.9 kWReference
Rated RPM2100Reference
Torque603.0 NmReference
Torque RPM1300Reference
Firing order1-5-3-6-2-4Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed partial power shiftReference
20-speed partial power shiftReference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Clutchwet discReference
Four power shift gears in four ranges, with power shuttle.Reference
Gears20 forward and reverseReference
Four power shift gears (1-4) in five ranges (A-E) with power shuttle. Available in 30 kph and 40 kph versions depending on market.Reference
PTO & Hydraulics
Typeclosed centerReference
Pressure200.0 barReference
Pump flow60.2 lpmReference
Pump flow96.1 lpmReference
Rear TypeII/IIINReference
Rear lift6841 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540E/1000Reference
Engine RPM540E@1754Reference
Engine RPM1000@2000Reference
Front PTOindependentReference
Dimensions
Wheelbase264 cmReference
Weight5391 kgReference
Front tire16.9R28Reference
Rear tire20.8R38Reference
Ag front16.9R28Reference
Ag rear20.8R38Reference
Length499 cmReference
Width236 cmReference
Height (cab)288 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps85Reference
Charging amps120Reference
Battery volts12Reference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
