Tractor · 2000Unverified

John Deere 6910S

Name: John Deere 6910S
Brand: John Deere

John Deere 6910S — Row-Crop tractor · 126 hp. Reference specifications; pending source verification.

The John Deere 6910S is a tractor rated at 126 hp, positioning it at the more powerful end of its class. Production of the 6910S ran from 2000 to 2001. It features a 6-cylinder turbocharged diesel engine, paired with four-wheel drive and a powershift transmission. The tractor has an operating weight of 5171 kg and is suited to farming operations covering 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

126 hp

Weight

5171 kg

Catalogue coverage

Variants represented

Richest spec table

83 rows

Recorded power

126 hp

Recorded weight

5171 kg

Transmissions

24-speed

Production years

2000-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

Built in Mannheim, Baden-WÃ¼rttemberg, GermanyReference

The John Deere 6910S featured a high power road mode for higher transport speeds.Reference

Four-wheel driveReference

Final drivesplanetaryReference

Differential lockelectro-hydraulic wet discReference

Power steeringReference

Hydraulic wet disc brakesReference

TechCenter cab standard with air-conditioning.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank207.0 LReference

Fuel tank249.8 LReference

Engine111.9 kWReference

John DeereReference

turbocharged dieselReference

6-cylinderReference

inlineReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Power111.9 kWReference

Rated RPM2100Reference

Torque623.8 NmReference

Torque RPM1400Reference

Firing order1-5-3-6-2-4Reference

StarterelectricReference

Starter volts12Reference

Starter power3.1 kWReference

Oil capacity19.7 LReference

Coolant capacity15.5 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Transmission

24-speedReference

18-speed full power shiftReference

TransmissionJohn Deere PowrQuadReference

Gears24 forward and reverseReference

TransmissionJohn Deere PowrShiftReference

Typefull power shiftReference

Gears18 forward and 7 reverseReference

TransmissionJohn Deere AutoPowrReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

PTO (claimed)94.0 kWReference

Typeclosed-center load sensingReference

Pressure200.0 barReference

Valves4Reference

Pump flow62.8 lpmReference

Pump flow96.1 lpmReference

Rear TypeII/IIINReference

Controlelectronic lower-link draft sensingReference

Rear Armstelescopic link endsReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000Reference

Engine RPM540@1995Reference

Engine RPM540E@1743Reference

Engine RPM1000@1995Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase264 cmReference

Weight5171 kgReference

Front tire16.9R28Reference

Rear tire20.8R38Reference

Ag front16.9R28Reference

Ag rear20.8R38Reference

Length456 cmReference

Width236 cmReference

Height (cab)288 cmReference

Shipping weight5171 kgReference

Max weight10001 kgReference

Clearance (front axle)54 cmReference

Front tread170 to 211 cmReference

Rear tread172 to 202 cmReference

John Deere 6910S attachments

front-end loaderReference

6910S Serial Numbers

Location:Serial number plate on the right side of the tractor frame, above the front axle.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Charging amps115Reference

Battery volts12Reference

Battery AH154Reference

Battery AH174Reference

Speeds

50 KPH transmission with 18.4-38 rear tires. Reverse speeds are 15% faster than forward.Reference

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
