Tractor · 2005Unverified

John Deere 70C

Name: John Deere 70C
Brand: John Deere

John Deere 70C — Milenio C Series · 70 hp. Reference specifications; pending source verification.

The John Deere 70C is a tractor with a rated power of 70 hp, a mid-range figure for its class. Manufactured from 2005 to 2015, the 70C features a 4-cylinder diesel liquid-cooled engine paired with four-wheel drive and a 16-speed gearbox. Its operating weight is listed as 2049 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

70 hp

Weight

2049 kg

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

70 hp

Recorded weight

2049 kg

Transmissions

16-speed

Production years

2005-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post mid-mount folding ROPS. Cab optional.Reference

Engine

VM Motori 3.0L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)52.2 kWReference

VM Motori D754Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke94 x 107 mmReference

Rated Power (gross)52.2 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Rated RPM2600Reference

Torque211.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.0 LReference

Coolant capacity9.0 LReference

Transmission

16-speedReference

8-speedReference

Gears16 forward and 8 reverseReference

Clutchmechanical dry discReference

Oil capacity35.0 LReference

Gears8 forward and reverseReference

PTO & Hydraulics

Pressure180.0 barReference

Pump flow39.0 lpmReference

Rear TypeII/IReference

Rear lift (at ends)2300 kgReference

Rear lift (at 24"/610mm)1450 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Engine RPM540@2430Reference

Engine RPM540E@1874Reference

Dimensions

Weight2049 kgReference

Front tire260/70R14Reference

Rear tire360/70R24Reference

Standard tires (ag)Front: 260/70R14. Rear: 360/70R24Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
