Tractor · 2002Unverified
John Deere 70F
John Deere 70F — Milenio F Series · 70 hp. Reference specifications; pending source verification.
The John Deere 70F is a tractor model with a rated power output of 70 hp, situated in the middle of its class for power. Manufactured from 2002 to 2010, it features a 4-cylinder diesel liquid-cooled engine, which drives a four-wheel drive system via a 16-speed gearbox. The listed weight of the 70F is 2049 kg, suitable for tasks covering areas of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
2049 kg
Catalogue coverage
Variants represented
2
Richest spec table
45 rows
Recorded power
70 hp
Recorded weight
2049 kg
Transmissions
16-speed
Production years
2002-2010
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post mid-mount folding ROPS.Reference
Variants
70ForchardReference
70VvineyardReference
Engine
VM Motori 3.0L 4-cyl dieselReference
Engine (gross)52.2 kWReference
VM Motori D754Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke94 x 107 mmReference
Rated Power (gross)52.2 kWReference
Rated RPM2600Reference
Torque210.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
8-speedReference
Gears16 forward and 8 reverseReference
Clutch254mm mechanical dry discReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow39.0 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2300 kgReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase184 cmReference
Weight2049 kgReference
Front tire250/80-18Reference
Rear tire380/85-24Reference
Standard tires (ag)Front: 250/80-18. Rear: 380/85-24Reference
Length361 cmReference
Height219 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
