Search/Tractor/John Deere/70V
Tractor · 2002Unverified

John Deere 70V

John Deere 70V — Milenio F Series · 70 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
70 hp
Weight
1850 kg
Hover a source tag to verify

Overview

DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post mid-mount folding ROPS.Reference

Variants

70ForchardReference
70VvineyardReference

Engine

VM Motori 2.1L 3-cyl dieselReference
Engine (gross)52.2 kWReference
VM Motori D703TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke94 x 100 mmReference
Rated Power (gross)52.2 kWReference
Rated RPM2600Reference
Torque205.0 NmReference
Torque RPM1700Reference
StarterelectricReference
Starter volts12Reference

Transmission

16-speedReference
8-speedReference
Gears16 forward and 8 reverseReference
Clutch254mm hydraulic dry discReference
Gears8 forward and reverseReference

PTO & Hydraulics

Typeopen centerReference
Pump flow39.0 lpmReference
Rear TypeI/INReference
Rear lift (at ends)1999 kgReference
Rear PTO Type540/540EReference

Dimensions

Wheelbase196 cmReference
Weight1850 kgReference
Front tire6.5/80-15Reference
Rear tire9.5-24Reference
Standard tires (ag)Front: 6.5/80-15. Rear: 9.5-24Reference
Length339 cmReference
Height206 cmReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
