Tractor · 1966Unverified
John Deere 710
John Deere 710 — Utility tractor · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2295 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two-wheel driveReference
Open operator station.Reference
Engine
John Deere 3.3L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine37.3 kWReference
John Deere 202D23LReference
dieselReference
4-cylinderReference
liquid-cooledReference
Wet-sleeved engine built in France.Reference
Displacement3.3 LReference
Bore/Stroke98 x 110 mmReference
Power37.3 kWReference
Rated RPM2400Reference
Idle RPM650-2400Reference
Operating RPM1500-2400Reference
Torque179.0 NmReference
Torque RPM1300Reference
Firing order1-3-4-2Reference
Transmission
10-speedReference
Gears10 forward and 3 reverseReference
Three gears (1-3) in three ranges (I-III), plus reverse (R) range with additional fourth road gear in range III.Reference
PTO & Hydraulics
Pump flow15.9 lpmReference
Pump flow32.2 lpmReference
Rear TypeIIReference
Rear lift1750 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/1000Reference
Engine RPM540@2250Reference
Engine RPM1000@2380Reference
Front PTO Type1000Reference
Dimensions
Weight2295 kgReference
Front tire6.50-16Reference
Rear tire16.9-30Reference
Ag front6.50-16Reference
Ag rear16.9-30Reference
Length353 cmReference
Height240 cmReference
710 Serial Numbers
Location:Serial number plate on the left side of the John Deere 710, to the rear of the oil pan.Reference
Speeds
With 14-30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
