Backhoe Loader · 2003Unverified
John Deere 710G
John Deere 710G — Backhoe loader tractor · 122 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
122 hp
Weight
23000 to 26500 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS canopy; cab with heat and A/C optionalReference
Engine
John Deere 6-cyl dieselReference
Engine91.0 kWReference
John Deere 6068TReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Power91.0 kWReference
Rated RPM2000Reference
Torque538.3 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity27.0 LReference
Transmission
4-speed full powershiftReference
TransmissionPowerShiftReference
Typefull powershiftReference
Gears4 forward and 3 reverseReference
Oil capacity15.1 LReference
Capacities
Fuel261.2 LReference
PTO & Hydraulics
Hydraulic system159.0 LReference
Typepressure compensated load sensing (PCLS)Reference
Capacity159.0 LReference
Pressure249.9 barReference
Total flow196.8 lpmReference
Dimensions
Wheelbase251 cmReference
Weight23000 to 26500 poundsReference
Front tire15-19.5Reference
Rear tire21L-28Reference
Industrial front15-19.5Reference
Industrial rear21L-28Reference
Industrial front16.5L-16.1Reference
Industrial rear20.5-25Reference
Length815 cmReference
Width241 cmReference
Height (ROPS)297 cmReference
Operating weight10432 kgReference
Operating weight12020 kgReference
Ground clearance35 cmReference
Backhoe & Loader
Dig depth214 to 270 inchesReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth543 cmReference
Digging depth (extended stick)685 cmReference
Reach from pivot685 cmReference
Reach from pivot (extended stick)812 cmReference
Loading height434 cmReference
Loading height (extended stick)487 cmReference
Bucket force7711 kgReference
Dipperstick force5329 kgReference
Speeds
With 21L-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
