Backhoe Loader · 2007Unverified
John Deere 710J
John Deere 710J — Backhoe loader tractor · 126 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
126 hp
Weight
23000 to 26000 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Backhoe loader tractorReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
ROPS canopy; cab with heat and A/C optionalReference
Engine
John Deere 6-cyl dieselReference
Engine94.0 kWReference
John Deere 6068HT067Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Power94.0 kWReference
Rated RPM2000Reference
Torque547.8 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity20.0 LReference
Coolant capacity23.4 LReference
Transmission
4-speed full powershiftReference
TransmissionPowerShiftReference
Typefull powershiftReference
Gears4 forward and 3 reverseReference
Capacities
Fuel261.2 LReference
PTO & Hydraulics
Hydraulic system151.4 LReference
Typepressure compensated load sensing (PCLS)Reference
Capacity151.4 LReference
Pressure249.9 barReference
Total flow196.8 lpmReference
Dimensions
Wheelbase251 cmReference
Wheelbase248 cmReference
Weight23000 to 26000 poundsReference
Front tire14.5/75-16.1Reference
Rear tire21L-28Reference
Industrial front14.5/75-16.1 (2WD)Reference
Industrial front15-19.5 (4WD)Reference
Industrial rear21L-28Reference
Industrial front16.5L-16.1Reference
Industrial rear20.5-25Reference
Length815 cmReference
Width241 cmReference
Height (ROPS)297 cmReference
Operating weight10432 kgReference
Operating weight11793 kgReference
Ground clearance35 cmReference
Backhoe & Loader
Dig depth214 to 268 inchesReference
Dump angle114 cmReference
Electrical
Charging systemalternatorReference
Charging amps90Reference
Batteries2Reference
Battery CCA950Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
John Deere Backhoe
Backhoe typeJohn Deere BackhoeReference
Digging depth543 cmReference
Digging depth (retracted stick)543 cmReference
Digging depth (extended stick)680 cmReference
2-Foot flat digging depth541 cmReference
2-Foot flat digging depth (retracted stick)541 cmReference
2-Foot flat digging depth (extended stick)683 cmReference
8-Foot flat digging depth518 cmReference
8-Foot flat digging depth (retracted stick)518 cmReference
8-Foot flat digging depth (extended stick)657 cmReference
Reach from pivot678 cmReference
Reach from pivot (retracted stick)678 cmReference
Reach from pivot (extended stick)817 cmReference
Loading height434 cmReference
Loading height (retracted stick)434 cmReference
Loading height (extended stick)518 cmReference
Bucket force7711 kgReference
Dipperstick force5329 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
