John Deere 7405
John Deere 7405 — Advantage Series · 105 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
105 hp
Weight
10750 to 11575 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Monterrey, MexicoReference
Original price was $43,600 in 1999Reference
The John Deere 7405 was one of the Advantage Series models designed to provide an economical alternative to the TEN series. The 7405 had the same power as the 7410 but without a cab, single transmission option, and different hydraulics.Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post folding ROPS.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
John Deere 6068Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
Air cleanerdry dual elementReference
Compression17:1Reference
Rated RPM2100Reference
Firing order1-5-3-6-2-4Reference
Coolant capacity18.0 LReference
Intake valve clearance0.356 mmReference
Exhaust valve clearance0.457 mmReference
Transmission
16-speed partial power shiftReference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Oil capacity56.8 LReference
Oil capacity64.4 LReference
Oil capacity68.1 LReference
Four power-shift gears (1-4) in four synchronized ranges (A-D). Power shuttle shifting between forward and reverse.Reference
PTO & Hydraulics
PTO (claimed)78.3 kWReference
Hydraulic system56.8 LReference
4WD Hydraulic system64.3 LReference
4WD Hydraulic system68.1 LReference
Typeconstant-flow load-sensingReference
Capacity56.8 LReference
4WD Capacity64.3 LReference
4WD Capacity68.1 LReference
Pressure189.6 barReference
Valves2Reference
Total flow66.2 lpmReference
Rear TypeIIReference
Controlposition and electro-hydraulic lower-link draft controlReference
Rear lift3615 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel207.0 LReference
Front axle6.4 LReference
Front hubs0.8 LReference
Dimensions
2WD Wheelbase270 cmReference
4WD Wheelbase264 cmReference
Weight10750 to 11575 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38 (2WD)Reference
Standard tires (ag)Front: 10.00-16. Rear: 18.4-38 (2WD)Reference
Standard tires (ag)Front: 14.9-28. Rear: 18.4-38 (4WD)Reference
Standard tires (ag)Front: 320/85R34. Rear: 320/90R50 (High Clearance)Reference
Length453 cmReference
2WD Shipping weight4876 kgReference
4WD Shipping weight5250 kgReference
4WD Ground clearance56 cmReference
2WD Ground clearance60 cmReference
High Clearance Ground clearance59 cmReference
Rack-and-pinion rear axle85 by 2806 mmReference
4WD Steering wheel220 cmReference
2WD Steering wheel221 cmReference
High Clearance Steering wheel226 cmReference
7405 Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.Reference
19981001Reference
19991719Reference
20001842Reference
20012050Reference
20022104Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery CCA950Reference
Battery volts12Reference
Battery AH110Reference
John Deere 7405 Height
ROPS283 cmReference
Exhaust280 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
