Tractor · 2009Unverified

John Deere 7425

Name: John Deere 7425
Brand: John Deere

John Deere 7425 — Row-Crop tractor · 123 hp. Reference specifications; pending source verification.

The John Deere 7425 is a tractor model with an approximate power output of 123 hp, placing it at the higher end of its class. It was produced in 2009 and features a 6-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and powershift transmission. The operating weight of the 7425 ranges from 10750 to 12210 pounds. It is designed for use in areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

123 hp

Weight

10750 to 12210 pounds

Catalogue coverage

Variants represented

Richest spec table

63 rows

Recorded power

123 hp

Recorded weight

4876 kg

Transmissions

16-speed four-speed power shift

Production years

2009-2009

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

Built in Saltillo, MexicoReference

Two- or four-wheel driveReference

Power steeringReference

Two-post ROPS. Cab optional.Reference

Engine

John Deere 6.8L 6-cyl dieselReference

Fuel tank207.0 LReference

Engine102.9 kWReference

John Deere PE6068Reference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Power102.9 kWReference

Compression16.9:1Reference

Rated RPM2100Reference

Idle RPM850-2250Reference

Operating RPM1500-2100Reference

Firing order1-5-3-6-2-4Reference

StarterelectricReference

Starter volts12Reference

Starter power3.0 kWReference

Oil capacity19.5 LReference

Coolant capacity20.0 LReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.457 mmReference

Transmission

16-speed four-speed power shiftReference

TransmissionPowrQuadReference

Typefour-speed power shiftReference

Gears16 forward and reverseReference

Clutchhydraulic wet discReference

Four power shift speeds (1-4) in four ranges (A-D) with power shuttle.Reference

PTO & Hydraulics

PTO (claimed)91.7 kWReference

Typeclosed center pressure flow compensatedReference

Rear TypeIIIN/IIReference

Rear lift (at 24"/610mm)3805 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@1995Reference

Engine RPM1000@1995Reference

Dimensions

2WD Wheelbase264 cmReference

4WD Wheelbase270 cmReference

Weight10750 to 12210 poundsReference

Front tire10.00-16Reference

2WD Rear tire18.4-38Reference

2WD Standard tires (ag)Front: 10.00-16. Rear: 18.4-38Reference

4WD Standard tires (ag)Front: 14.9-28. Rear: 18.4Reference

Length477 cmReference

2WD Height (steering wheel)221 cmReference

4WD Height (steering wheel)220 cmReference

2WD Shipping weight4876 kgReference

4WD Shipping weight5538 kgReference

Rack-and-pinion rear axle85 by 2806 mmReference

7425 Serial Numbers

Location:Serial number plate on right side of tractor frame.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps90Reference

Charging volts14Reference

Battery volts12Reference

Battery AH154Reference

Speeds

With 18.4-38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
