Tractor · 1999Unverified
John Deere 7510 Hi-Crop
John Deere 7510 Hi-Crop — High-Clearance tractor · 115 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
High-Clearance tractorReference
Built in Waterloo, Iowa, USAReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
ComfortGard cab standard.Reference
Variants
7510row-cropReference
7510 Hi-Crophigh clearanceReference
Engine
John Deere 6.8L 6-cyl dieselReference
Engine100.7 kWReference
John Deere PowerTech 6068Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
Power100.7 kWReference
Air cleanerdual paper elementsReference
Compression17:1Reference
Rated RPM2100Reference
Torque535.6 NmReference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Coolant capacity18.9 LReference
Oil capacity18.9 LReference
Transmission
12-speed fully synchronizedReference
16-speed partial power shiftReference
TransmissionJohn Deere SyncroPlusReference
Typefully synchronizedReference
Gears12 forward and 4 reverseReference
Clutchwet discReference
2WD Oil capacity56.8 LReference
4WD Oil capacity64.4 LReference
Oil typeJD Hy-GardReference
Three synchronized speeds (plus reverse) in four synchronized ranges (A-D). Synchronized shuttle shifting.Reference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Gears16 forward and reverseReference
Four power shift speeds (1-4) in four synchronized ranges (A-D). Right- or left-hand power shuttle.Reference
PTO & Hydraulics
PTO (claimed)85.8 kWReference
2WD Hydraulic system56.8 LReference
4WD Hydraulic system64.3 LReference
4WD Hydraulic system60.6 LReference
4WD Hydraulic system68.1 LReference
Typeclosed center pressure flow compensated (PFC)Reference
2WD Capacity56.8 LReference
4WD Capacity64.3 LReference
4WD Capacity60.6 LReference
4WD Capacity68.1 LReference
Pressure200.0 barReference
Valves2 to 4Reference
Pump flow60.6 lpmReference
Pump flow98.4 lpmReference
Rear Type2Reference
Rear Type3N/2Reference
2WD Rear lift3356 kgReference
4WD Rear lift3805 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel189.2 LReference
7510 Hi-Crop Serial Numbers
Location:Above front axle on the 7510's main frame.Reference
200030001Reference
200150001Reference
200270001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging amps120Reference
Battery CCA925Reference
Battery volts12Reference
Battery Group31Reference
Dimensions
2WD Clearance (front axle)89 cmReference
4WD Clearance (front axle)74 cmReference
Clearance (rear axle)102 cmReference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
