Tractor · 2005Unverified

John Deere 75C

Name: John Deere 75C
Brand: John Deere

John Deere 75C — Milenio C Series · 75 hp. Reference specifications; pending source verification.

The John Deere 75C is a 75 hp tractor, positioned in the middle of its class in terms of power output. It was manufactured from 2005 to 2015. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, coupled with a 16-speed gearbox and four-wheel drive. Its listed weight is 2049 kg, suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Max power

75 hp

Weight

2049 kg

Catalogue coverage

Variants represented

Richest spec table

68 rows

Recorded power

75 hp

Recorded weight

2049 kg

Transmissions

16-speed

Production years

2005-2015

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Two-post mid-mount folding ROPS. Cab optional.Reference

Engine

VM Motori 3.0L 4-cyl dieselReference

Fuel tank50.0 LReference

Engine (gross)55.9 kWReference

VM Motori T754TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke94 x 107 mmReference

Rated Power (gross)55.9 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.0 LReference

Coolant capacity9.0 LReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,600 RPMReference

Bore and stroke3.70x4.21 inchesReference

Cooling systemliquid-cooledReference

Transmission

16-speedReference

8-speedReference

Gears16 forward and 8 reverseReference

Clutchmechanical dry discReference

Oil capacity35.0 LReference

Gears8 forward and reverseReference

forward and reverse options16 F and 8R | 8F and 8RReference

Wheel Drive4WDReference

PTO & Hydraulics

Pressure180.0 barReference

Pump flow39.0 lpmReference

Rear TypeII/IReference

Rear lift (at ends)2300 kgReference

Rear lift (at 24"/610mm)1450 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Engine RPM540@2430Reference

Engine RPM540E@1874Reference

Dimensions

Weight2049 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery volts12Reference

General

Make & ModelGoldiniReference

Rollover protective structureTwo-post mid-mount folding ROPSReference

Country of manufacturerItalyReference

Capacities

Capacity181.2 ciReference

Crankcase oil volume5.3 qtsReference

Power

Max Power75 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,430 RPMReference

Steering & brakes

BrakesMechanical Wet DiscReference

Steering typePowerReference

Hydraulics

Maximum operating pressure2,611 psiReference

Rear Hitch category (SAE designation)Category II/IReference

Rear Hitch maximum lift capacity2,300.2 kgReference

Dimensions & weight

Overall weight2,049.8 kgReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
