Tractor · 2009Unverified
John Deere 75F
John Deere 75F — Milenio F Series · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
2500 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
John Deere 2.9L 3-cyl dieselReference
Engine (gross)55.2 kWReference
John DeereReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Rated Power (gross)55.2 kWReference
Rated RPM2500Reference
Torque248.0 NmReference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
8-speedReference
Gears16 forward and 8 reverseReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow35.2 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2500 kgReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase193 cmReference
Weight2500 kgReference
Front tire250/80-18Reference
Rear tire380/85-24Reference
Standard tires (ag)Front: 250/80-18. Rear: 380/85-24Reference
Length369 cmReference
Height215 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
