Industrial Tractor · 1965Unverified

John Deere 760

Name: John Deere 760
Brand: John Deere

John Deere 760 — Industrial tractor · 143 hp. Reference specifications; pending source verification.

The John Deere 760 is an industrial tractor model with a rated power of 143 hp, placing it at the more powerful end of its class. Production of the 760 model occurred from 1965 to 1970. It features a 6-cylinder diesel liquid-cooled engine combined with two-wheel drive and a powershift transmission. The 760 has an operating weight of 6758 kg and is suitable for use on areas of 200-800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

143 hp

Weight

6758 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

143 hp

Recorded weight

6758 kg

Transmissions

8-speed power shift

Production years

1965-1970

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Industrial tractorReference

Built in Waterloo, Iowa, USAReference

Two-wheel driveReference

Power steeringReference

Hydraulic powered wet disc brakesReference

Open operator station.Reference

Engine

John Deere 8.7L 6-cyl dieselReference

Engine (net)106.6 kWReference

John DeereReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement8.7 LReference

Bore/Stroke121 x 127 mmReference

Power (net)106.6 kWReference

Air cleanerdryReference

Compression16:1Reference

Rated RPM2200Reference

Torque503.1 NmReference

Torque RPM1300Reference

Starter volts24Reference

Oil capacity18.9 LReference

Coolant capacity34.1 LReference

Transmission

8-speed power shiftReference

Typepower shiftReference

Gears8 forward and 3 reverseReference

Clutch304.8mm dry discsReference

Oil capacity60.6 LReference

Capacities

Fuel276.3 LReference

PTO & Hydraulics

Hydraulic system60.6 LReference

Capacity60.6 LReference

Pressure137.9 barReference

Valves2Reference

Total flow97.3 lpmReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type1000Reference

Dimensions

Wheelbase242 cmReference

Weight6758 kgReference

Front tire11.00-16Reference

Rear tire18.00-25Reference

Industrial front11.00-16Reference

Industrial rear18.00-25Reference

Industrial front10.00-15Reference

Industrial rear23.5-25Reference

Length399 cmReference

Width243 cmReference

Height (hood)163 cmReference

Height (exhaust)275 cmReference

Operating weight6758 kgReference

Ground clearance33 cmReference

Speeds

With 18.00-25 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
