Industrial Tractor · 1969Unverified
John Deere 760A
John Deere 760A — Industrial tractor · 159 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
159 hp
Weight
15250 to 15840 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Waterloo, Iowa, USAReference
Two-wheel driveReference
Final drivesinboard planetaryReference
Differential lockhydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station. Four-post ROPS and cab available.Reference
Engine
John Deere 8.7L 6-cyl dieselReference
Fuel tank261.2 LReference
Engine (gross)118.6 kWReference
Engine (net)113.3 kWReference
John DeereReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement8.7 LReference
Bore/Stroke121 x 127 mmReference
Power (net)113.3 kWReference
Power (gross)118.6 kWReference
Air cleanerdryReference
Rated RPM2200Reference
Idle RPM800-2200Reference
Torque562.7 NmReference
Torque RPM1100Reference
StarterelectricReference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity34.1 LReference
Transmission
8-speed power shiftReference
Typepower shiftReference
Gears8 forward and 3 reverseReference
PTO & Hydraulics
Typeclosed centerReference
Pressure137.9 barReference
Pump flow98.4 lpmReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Wheelbase242 cmReference
Weight15250 to 15840 poundsReference
Front tire11.00-15Reference
Rear tire23.5-25Reference
Industrial front11.00-15Reference
Industrial rear23.5-25Reference
Industrial front10.00-15Reference
Industrial front14.00-17.5Reference
Length414 cmReference
Width243 cmReference
Height (hood)162 cmReference
Height (exhaust)279 cmReference
Open Operating weight6917 kgReference
ROPS Operating weight7185 kgReference
Ground clearance34 cmReference
Front tread177 cmReference
Rear tread183 cmReference
Electrical
Charging systemalternatorReference
Batteries2Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
