Tractor · 1993Unverified
John Deere 7700
John Deere 7700 — Row-Crop tractor · 150 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
150 hp
Max power
94.0 kW
Weight
13870 to 15505 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Waterloo, Iowa, USAReference
Original price was $68,000 in 1996Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Differential hydraulic wet disc brakesReference
ComfortGard cab standard with air-conditioning.Reference
Engine
John Deere 7.6L 6-cyl dieselReference
Engine (net)111.9 kWReference
Drawbar (tested)87.0 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.6 LReference
Bore/Stroke116 x 121 mmReference
Rated Power (net)111.9 kWReference
Air cleanerdual dry elementReference
Compression15.8:1Reference
Rated RPM2100Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Coolant capacity25.1 LReference
Max power94.0 kWReference
Power at rated engine speed94.0 kWReference
Max power87.0 kWReference
Max power97.5 kWReference
Max power83.2 kWReference
Transmission
16-speed partial power shiftReference
19-speed full power shiftReference
TransmissionJohn Deere PowrQuadReference
Typepartial power shiftReference
Gears16 forward and 12 reverseReference
Clutchwet discReference
The PowrQuad was the standard transmission on the Deere 7800. It consists of four speeds (1-4) in four ranges (A-D).Reference
TransmissionJohn Deere PowerShiftReference
Typefull power shiftReference
Gears19 forward and 7 reverseReference
PTO & Hydraulics
PTO (claimed)94.0 kWReference
PTO (tested)97.5 kWReference
Hydraulic system86.7 LReference
Typeclosed centerReference
Capacity86.7 LReference
Pressure200.0 barReference
Valves2 to 3Reference
SCV flow96.1 lpmReference
Rear TypeIIIN/IIReference
Controlposition and draft controlReference
Rear lift4048 kgReference
Rear lift4558 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Capacities
Fuel344.4 LReference
Dimensions
2WD Wheelbase290 cmReference
4WD Wheelbase279 cmReference
Weight13870 to 15505 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
Ag front10.00-16Reference
Ag rear18.4-38Reference
Length475 cmReference
Height (cab)300 cmReference
Shipping weight6291 kgReference
4WD Operating weight7033 kgReference
Rack-and-pinion rear axle91 by 2438 mmReference
Rack-and-pinion rear axle91 by 2806 mmReference
Rack-and-pinion rear axle91 by 2997 mmReference
Rear tread152 to 217 cmReference
Rear tread152 to 254 cmReference
Rear tread152 to 275 cmReference
John Deere 7700 attachments
front-end loaderReference
7700 Serial Number Location
Serial number tag on the right side of the 7700 tractor frame, above the front axle.Reference
7700 Serial Numbers
19931001Reference
19944601Reference
19957295Reference
199610001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps140Reference
Battery volts12Reference
Attachment overview
John Deere 720 loaderReference
John Deere 725 loaderReference
John Deere 740 loaderReference
Test results
OECD 1666: diesel PowrQuad 4WDReference
OECD 1667: diesel Powershift 4WDReference
Diesel PowrQuad 4WDMay 26 - June 21, 1993Link: OCED Tractor Test 1666 fileReference
PTO performanceReference
Fuel use28.4 l/hourReference
Fuel use29.9 l/hourReference
Drawbar performanceReference
Fuel use30.3 l/hourReference
Max pull7895 kgReference
Diesel Powershift 4WDApril 22 - May 21, 1993Link: OCED Tractor Test 1667 fileReference
Fuel use29.1 l/hourReference
Fuel use29.5 l/hourReference
Gear 11 used for power test.Reference
Max pull6762 kgReference
Gear 5 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
