Tractor · 2005Unverified

John Deere 7815

Name: John Deere 7815
Brand: John Deere

John Deere 7815 — Row-Crop tractor · 167 hp. Reference specifications; pending source verification.

The John Deere 7815 is a tractor with a rated power of 167 hp, placing it at the higher end of its category. Built from 2005 to 2010, this tractor features a 6-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. Its operating weight is listed at 8101 kg, making it suitable for operations covering an area of 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

167 hp

Weight

8101 kg

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

167 hp

Recorded weight

8101 kg

Transmissions

16-speed partial power shift

Production years

2005-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Row-Crop tractorReference

Built in Montenegro, BrazilReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Engine

John Deere 6.8L 6-cyl dieselReference

Engine150.6 kWReference

John DeereReference

dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.8 LReference

Bore/Stroke106 x 127 mmReference

Power150.6 kWReference

Fuel systemDE10 electronic rotary injectionReference

Air cleanerdry with pre-cleanerReference

Compression17:1Reference

Rated RPM2100Reference

Idle RPM875-2200Reference

Torque918.1 NmReference

Torque RPM1400Reference

Starter volts12Reference

Coolant capacity29.2 LReference

Oil capacity26.0 LReference

Oil change250 hReference

Transmission

16-speed partial power shiftReference

TransmissionJohn Deere PowrQuad PlusReference

Typepartial power shiftReference

Gears16 forward and reverseReference

Clutchhydraulic wet discReference

Oil capacity107.9 LReference

Four gears (1-4) in four ranges (A-D) with left-hand power shuttle. Push-button power shifting between gears, synchronized range shifting using the clutch.Reference

PTO & Hydraulics

PTO (claimed)124.5 kWReference

Hydraulic system107.9 LReference

Typeclosed center load sensingReference

Capacity107.9 LReference

Pressure210.0 barReference

Valves2 to 4Reference

Pump flow121.1 lpmReference

SCV flow113.9 lpmReference

Rear Type3/3NReference

Rear lift (at 24"/610mm)4599 kgReference

Rear lift (at 24"/610mm)6350 kgReference

Rear PTOindependentReference

Clutchhydraulic wet discReference

Rear PTO Type540/1000Reference

Engine RPM540@1950Reference

Engine RPM1000@1950Reference

Capacities

Fuel391.7 LReference

Front hubs1.9 LReference

Front diff.14.4 LReference

Front diff.22.4 LReference

Dimensions

Wheelbase286 cmReference

Weight8101 kgReference

Front tire16.9-30Reference

Rear tire20.8-42Reference

Standard tires (ag)Front: 16.9-30. Rear: 20.8-42Reference

Optional tires (ag)Front: 16.9-30. Rear: 20.8R42Reference

Optional tires (ag)Front: 600/65R28. Rear: 710/70R38RReference

Length539 cmReference

Length570 cmReference

Width243 cmReference

Width280 cmReference

Height (cab)313 cmReference

Ballasted weight10900 kgReference

Clearance (drawbar)51 cmReference

7815 Serial Numbers

Location:Right-front of engineReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps120Reference

Batteries2Reference

Battery CCA750Reference

Battery volts12Reference

Battery AH100Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
