Tractor · 2019Unverified
John Deere 7R 210
John Deere 7R 210 — 7R Series · 210 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
210 hp
Max power
153.1 kW
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Waterloo, Iowa, USAReference
Original price was $246 in 884 with 2020Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic rearReference
Differential lockelectro-hydraulic frontReference
Power steeringReference
Cab standard with air-conditioning.Reference
Engine
John Deere 6.8L 6-cyl dieselReference
Engine (gross)156.6 kWReference
Engine (max)172.3 kWReference
Drawbar (tested)127.3 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke106 x 127 mmReference
EmissionsTier IVReference
Rated Power (gross)156.6 kWReference
Maximum Power (gross)172.3 kWReference
Fuel systemelectronic high-pressure common railReference
Compression17.2:1Reference
StarterelectricReference
Starter volts12Reference
Max power153.1 kWReference
Power at rated engine speed135.9 kWReference
Max power127.3 kWReference
Transmission
23-speed full power shiftReference
infinitely variable transmissionReference
Transmissione23Reference
Typefull power shiftReference
Gears23 forward and 11 reverseReference
Typeinfinitely variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)126.8 kWReference
PTO (tested)153.1 kWReference
Hydraulic system65.1 LReference
Hydraulic system85.2 LReference
Typeclosed-center pressure flow compensatedReference
Capacity65.1 LReference
Capacity85.2 LReference
Pressure204.0 barReference
Rear valves4 to 6Reference
Front valves0 to 1Reference
Pump flow162.8 lpmReference
Pump flow223.3 lpmReference
SCV flow132.5 lpmReference
SCV flow124.9 lpmReference
Rear TypeIII/IIINReference
Controlelectro-hydraulic draft sensingReference
Rear lift (at 24"/610mm)6894 kgReference
Rear lift (at 24"/610mm)7847 kgReference
Front HitchIIINReference
Front lift (at ends)3488 kgReference
Front lift (at 24"/610mm)3172 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Engine RPM540@1950Reference
Engine RPM1000@1950Reference
Engine RPM540E@1750Reference
Engine RPM1000E@1750Reference
Front PTOindependentReference
Clutch1000:1940Reference
Front PTO Type1000 (1.375)Reference
Front PTO Type1000 (1.75)Reference
Power at rated PTO speed148.4 kWReference
Capacities
Fuel461.8 LReference
Fuel511.0 LReference
Exhaust fluid (DEF)26.1 LReference
Dimensions
Wheelbase292 cmReference
Front tire420/90R30Reference
Rear tire480/80R46Reference
Standard tires (ag)Front: 420/90R30. Rear: 480/80R46Reference
Length551 cmReference
Clearance (front axle)49 cmReference
Rack-and-pinion rear axle109 by 3009 mmReference
Rack-and-pinion rear axle109 by 2550 mmReference
Rack-and-pinion rear axle109 by 2806 mmReference
Rack-and-pinion rear axle119 by 2550 mmReference
Rack-and-pinion rear axle119 by 3009 mmReference
Front tread152 to 223 cmReference
John Deere 7R 210 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps210Reference
Charging amps250Reference
Batteries2Reference
Battery CCA925Reference
Battery volts12Reference
Battery Group31Reference
Test results
Diesel e23 4WDSeptember 5 - 8, 2017Link: OCED Tractor Test 2179A fileReference
PTO performanceReference
Fuel use41.6 l/hourReference
Fuel use39.4 l/hourReference
Drawbar performanceReference
Fuel use39.0 l/hourReference
Gear 10 used for power test.Reference
Max pull9756 kgReference
Gear 5 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
