Tractor · 1997Unverified
John Deere 8100T
John Deere 8100T — Agricultural Crawler tractor · 162 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
162 hp
Max power
133.3 kW
Weight
23650 to 24470 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Agricultural Crawler tractorReference
Built in Waterloo, Iowa, USAReference
DrivecrawlerReference
Steeringhydrostatic powerReference
CommandView Cab standardReference
Variants
8100wheeled tractorReference
8100Tcrawler tractorReference
Engine
John Deere 8.1L 6-cylReference
Drawbar (tested)103.3 kWReference
John DeereReference
turbocharged intercooledReference
6-cylinderReference
liquid-cooledReference
Displacement8.1 LReference
Bore/Stroke116 x 129 mmReference
Air cleanertwo paper elementsReference
Compression16.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity21.5 LReference
Coolant capacity34.0 LReference
Max power133.3 kWReference
Power at rated engine speed120.9 kWReference
Max power103.3 kWReference
Transmission
16-speed full powershiftReference
Typefull powershiftReference
Gears16 forward and 4 reverseReference
Oil capacity246.1 LReference
PTO & Hydraulics
PTO (claimed)119.3 kWReference
PTO (tested)133.3 kWReference
Hydraulic system246.0 LReference
Typepressure/flow compensated (PFC)Reference
Capacity246.0 LReference
Pressure200.0 barReference
Valves3 to 5Reference
Pump flow113.6 lpmReference
Pump flow143.8 lpmReference
Rear TypeIII/IIINReference
Rear lift7098 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Capacities
Fuel492.1 LReference
Dimensions
Wheelbase226 cmReference
Weight23650 to 24470 poundsReference
16-inch tracksReference
Length525 cmReference
Length557 cmReference
Width263 cmReference
Height (cab)312 cmReference
Shipping weight10727 kgReference
Operating weight11099 kgReference
Ground clearance44 cmReference
Ground clearance55 cmReference
Electrical
Charging systemalternatorReference
Charging amps140Reference
Batteries2Reference
Battery volts12Reference
John Deere 8100T Tracks
Width40 cmReference
Width60 cmReference
Width76 cmReference
Test results
Diesel 16-speed crawlerApril 15 - 28, 1998Link: OCED Tractor Test 1744 fileReference
PTO performanceReference
Fuel use37.9 l/hourReference
Fuel use37.1 l/hourReference
Drawbar performanceReference
Fuel use36.7 l/hourReference
Gear 8 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
